Supermicro H12SSL-i Motherboard + AMD EPYC 7532 CPU , 32 Cores 2,4 GHz~3,3 GHz

Product Description

Package include: 1x AMD EPYC 7532 CPU

                               1x Supermicro H12SSL-i motherboard


AMD EPYC™ 7532

Specifications
# of CPU Cores
32
# of Threads
64
Base Clock
2.4GHz
Max Boost Clock
Up to 3.3GHz
Total L3 Cache
256MB
Package
SP3
Socket Count
1P/2P
PCI Express® Version
PCIe 4.0 x128
Default TDP / TDP
200W
System Memory
System Memory Specification
Up to 3200MHz
System Memory Type
DDR4
Memory Channels
8
Per Socket Mem BW
204.8 GB/s
Key Features
Supported Technologies
AMD Infinity Architecture
Workload Affinity
Analytics
CAE/CFD/FEA
ERM/SCM/CRM apps
Media streaming
Medium capacity data mgmt (NR/RDBMS)
VDI
VM Density
Foundation
Product Family
AMD EPYC™
Product Line
AMD EPYC™ 7002 Series
Platform
Server
OPN Tray
100-000000136
OPN PIB
100-000000136WOF



Specifications

Product SKUs

MBD-H12SSL-i
  • H12SSL-i
MBD-H12SSL-i-O
  • H12SSL-i (Retail Pack)

Physical Stats

Form Factor
  • ATX
Dimensions
  • 12" x 9.6" (30.5cm x 24.4cm)

Processor/Chipset

CPU
  • Single AMD EPYC™ 7003/7002 Series Processor
    (7003 Series Processor drop-in support requires BIOS version 2.0 or newer)
  • Socket SP3
Cores
  • Up to 64 Cores
Chipset
  • System on Chip

System Memory

Memory Capacity
  • 8 DIMM slots
  • Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM
  • 8-channel memory bus
Memory Type
  • DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs
DIMM Sizes
  • 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage
  • 1.2V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)

On-Board Devices

SATA
  • SATA3 (6 Gbps)
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2500 BMC
Network Controllers
  • Dual gigabit LAN via Broadcom BCM5720
  • 1 Realtek RTL8211F PHY (dedicated IPMI)
VGA
  • ASPEED AST2500 BMC

Input / Output

SATA
  • 8 SATA3 (6 Gbps) ports
SATA/NVMe Hybrid
  • 8 SATA3 or 2 NVMe via single SlimSAS x8
LAN
  • 2 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 6 USB 3.0 ports
    (4 rear + 2 via header)
VGA
  • 1 VGA port
Others
  • 1 COM port (rear)
  • 2 SATA DOM power connectors
  • 1 TPM 2.0 header

Expansion Slots

PCI-Express
  • 5 PCI-E 4.0 x16
  • 2 PCI-E 4.0 x8

M.2
  • Interface: 2 PCI-E 4.0 x4
  • Form factor: 2280, 22110
  • Key: M-key

Chassis ( Optimized for H12SSL-i )

1U
  • SC813MFTQC-350CB2
  • SC813MFTQC-R407CB
2U
  • SC213BAC8-R1K23LPB
  • SC216BE1C4-R1K23LPB
  • SC825MBTQC-R802LPB
  • SC825TQC-R802LPB
  • SC826BE1C4-R1K23LPB
  • SCLA26AC12-R920LP1
3U
  • SC835TQC-R802B
  • SC836BE1C-R1K23B
Mid-Tower
  • SC732i-903B
Tower/4U
  • SC745BAC-R1K23B
  • SC846BE1C-R1K23B


Server(s) ( with H12SSL-i )

Model(s)
  • AS -2014S-TR
  • AS -3014TS-i

System BIOS

BIOS Type
  • AMI 256Mb SPI Flash EEPROM
BIOS Features
  • Plug and Play (PnP)
  • DMI 2.3
  • PCI 2.2
  • ACPI 5.1
  • USB Keyboard Support
  • SMBIOS 3.1.1

Management

Software
  • Super Doctor 5
  • Watch Dog
  • NMI
  • SUM
  • IPMI 2.0, KVM with dedicated LAN
Power Configurations
  • ACPI Power Management
  • Power-on mode control for AC power loss recovery

PC Health Monitoring

CPU
  • Monitors CPU Core Voltages, +3.3V, +5V, +5V standby, +3.3V standby
  • CPU switching voltage regulator
  • Supports system management utility
  • VBAT
FAN
  • Up to 7-fan status tachometer monitoring
  • Up to 7 4-pin fan headers
  • Dual Cooling Zone
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • CPU Thermal Trip Support
  • Thermal control for 7x Fan connectors
  • I²C Temperature Sensing Logic
LED
  • CPU / System Overheat LED
Other Features
  • Chassis Intrusion Detection
  • Chassis Intrusion Header
  • UID


Operating Environment / Compliance

Environmental Specifications
  • Operating Temperature:
    10°C to 35°C (50°F to 95°F)
  • Non-operating Temperature:
    -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
    8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
    5% to 95% (non-condensing)
Parts List

Bulk Pack List


Part Number Qty Description
H12SSL-i MBD-H12SSL-i-B 1 H12SSL-i Motherboard




I/O Shield MCP-260-00042-0N 1 STD I/O SHIELD FOR X9 SOCKET R SERVER MB
