Note:1. no need the gateway,connect wifi directly.
2. R11,RT1,RT6 for single color remote. R12,RT2,RT7 For CCT Dual white color remote.
3. R11 R12 need CR2032 Battery,RT1 RT6 RT2 RT7 need AAA*2 ( not include )
Brand:SKYDANCE
Model: WT1
Type:Wifi 2CH Led Controller,universal for Single color
App:Smart Life
Features
● Used for control single color or color temperature LED strip.
● DC power socket input and 2 channel constant voltage output.
● Tuya APP cloud control, support on/off, color temperature and brightness adjust, delay turn on/off light,
timer run, scene and music play function.
● Voice control, support amazon ECHO and TmallGenie smart speaker.
● Match with RF 2.4G remote control optional.
● User need set light type by press key before Tuya APP network connection and match RF remote of the same light type.
● Each WT1 controller can also work as WiFi-RF converter, then use Tuya APP to control one or more RF LED controller
or RF LED dimming driver synchronously.
● Connect with external push switch to achieve on/off and 0-100% dimming function.
Technical Parameters:
Input voltage: DC12V,24V,36V
Input current: 10.5A
Output voltage: 2 x (12-36)VDC
Output current: 2CH,5A/CH
Output Power: 2 x (60-180)W
Output type: Constant voltage
Input signal: Tuya APP + RF + Push Dim
Control distance: 30m(Barrier-free space)
Dimming gray scale: 4096 (2^12) levels
Dimming Range: 0～100％
Dimming curve: Logarithmic
PWM Frequency: 2000Hz (default)
For SMD 5050/5630/3528/Cob Led strip
Pack: according your choice
