• TinySA Ultra+ ZS406 Spectrum Analyzer with 50W Attenuator, 2025 Upgraded 100kHz-5.4GHz V0.4.6 Portable Frequency Analyzer with 32Gb Card, 2-in-1 Signal Generator 100kHz to 900MHz Input

    • [50dB Fixed Attenuator Spec] Rated to 50 Watts, DC to 3 GHz, N Female to N Male Directional. Attenuation: 50 dB ± 2.5 dB, Impedance: 50 Ω; VSWR and Attenuation Accuracy: 1.20:1 Max. Connector: N(M) Input N(F) Output. Black Anodized Aluminum Heatsink Body
    • [Upgraded TinySA Ultra] Produced by Hugen, AURSINC Tinysa ULTRA+ zs406 owns high performance frequency in 100khz to 900MHz, and when in ultra mode, the analyzer can reach 5.4GHz. With new 4'' touchscreen display and installed with the latest hardware system V0.4.6. Built-in 32Gb micro SD card for data transfer and storage
    • [Frequency Range] Tiny sa ultra measures from 100KHz-5.4GHz: Spectrum Analyzer for 0.1MHz-900MHz, with Ultra mode enabled, level calibrated up to 6GHz, can observe signals up to 12GHz. Switchable resolution bandpass filters from 200Hz-850kHz, you can fast and accurate execute measurement tests. Color display showing max 450 points providing gapless covering up to the full frequency range
    • [2 in 1 Device] When not used as Spectrum Analyzer it can be used as Signal Generator, MF/HF/VHF sinus output between 100kHZ-900MHz, UHF square wave output between 800mHz-4.4GHz, Mixing signal output is between 4.4GHz-5.4GHz. Built-in calibration signal generator that is used for automatic self test and low inputcalibration
    • [PC CONTROL] This tinysa ultra can connect to a PC via USB, Tinysa-APP directly transfers data to the computer. The USB interface implements the Serial over USB (CDC) protocol and there is a large set of commands that can be invoked over the serial interface. These command can be used to perform measurements or update internal settings. The driver for Windows will install automatically after connecting to a Windows PC. The driver for Linux is built into the kernel
    • [200Hz-850kHz RBW] RBW frequency from 200hz to 850khz which can be set to match the measurement requirements, meet SBB two-tone test requirements and fast scanning. The RBW is as low as 200Hz, which can effectively distinguish adjacent signals and meet the requirements of SSB dual-satellite inter-modulation test. Input Step attenuator from 0dB to 31dB (can not be used not in combination with LNA)
    • [What You Get] 1x Tinysa ULTRA+ zs406 Spectrum Analyzer(4inch touchscreen, 5000mah rechargeable battery); 1x 50W Attenuator; 2x 30cm ALSR100 SMA cables; 1 x USB Type-C data cable; 1x SMA-SMA barrel connector; 1x TLanyard and touch plectrum; 1x Antenna with SMA connector; 1x 32GB MicroSD card(plugged in the host), 1x Stylus Pen

Upgraded 4.0Inch TinySA ULTRA+ Spectrum Analyzer, 100kHz to 5.4GHz Widely Measure Range,New Version V0.4.6

This New Version V0.4.6 ZS406 tinysa ULTRA+ Spectrum Analyzer with 4.0 inch 480 x 320 large touchscreen display, 100kHz to 5.4GHz widely measure range, with the new ESD protection function,and built-in 32Gb micro SD card, can directly record data to the card ,which is convenient for your data sharing and storage.

Compared with the 2.8 inch tinysa, upgraded TinySA ULTRA+ has a larger screen size, a wider measurement range, faster and more accurate measurement performance, you can easily cope with measurement test in various fields.

2

2-In-1 Multifunctional Frequency Analyzer & Signal Generator

When not used as Spectrum Analyzer it can be used as Signal Generator,with sine wave output between 0.1-800MHz or square wave or dual tone output up to 4.4GHz.

Built-in calibration signal generator that is used for automatic self test and low input calibration.

7

4.0 inch Large Touchscreen

With 4.0 inch 480 x 320 high definition screen, which can let you operate and see the data more clearly, give you a better using experience.

tinysa ultra+ ZS406 spectrum analyzer

Built-in 5000mah rechargeable battery

  • Built-in 5000mah rechargeable lithium battery, can work continuously for more than 3 hours, with type-C charging cable and LED charging indicator
  • It can be fully charged within 3 hours, has an long battery life, without the need for frequent charging

7

32GB TF SD card Included

Built-in 32Gb mi-cro SD card, can directly record data to the card ,which is convenient for your data sharing and storage.


7

PC Control Available

Connected to a PC via USB it becomes a PC controlled Spectrum Analyzer or Signal Generator.Tinysa-APP transfers data directly to the computer.The USB interface implements CDC protocol and there is a large set of commands that can be invoked over the serial interface. These command can be used to perform measurements or update internal settings. The driver for Windows will install automatically after connecting to a Windows PC. The driver for Linux is built into the kernel.

tinysa ultra+ spectrum analyzer
9
Attenuator 50W TinySA Ultra Spectrum Analyzer NanoVNA DC-3GHz 50 dB
