TAFAU

Adjust Damping Coilovers For Holden Commodore VE Wagon 2008-2013








Application



For Holden Commodore VE Sedan 2006-2013

For Holden Commodore VE Wagon 2008-2013

For Holden Commodore VE  Ute   2007-2013

Note: Don't Fit For VE SSV Commodore 6.0 model 2007

Package included



2x Front coil-overs
2x Rear coil-overs
2x C spanners
2x Allen wrench
1x Sticker




Specification


    Height adjustable: Yes, lowering 25-75mm depending on the vehicle models
    Damping adjustable: Available, 24 levels of rebound damping force
    Top mounts: Front and rear OE top mounts required
    Camber adjustable: Not available
    Spring rate Front: 7 kg/mm (392 lbs/in)
    Spring rate Rear: 8 kg/mm (448 lbs/in)
    Front spring inner diameter: 70.5 mm
    Rear spring inner diameter: 70.5 mm
    Spring length Front: 200 mm
    Spring length Rear: 185 mm
    Spring Preload advised: 7-10 mm
    Shoc
    k Type: Twin tube

       Details











































      Feature

      1. Lowered height adjustment from 25-75mm which allows a lower center of gravity and also adds a more aggressive stance
      2. Adjustable pre-load spring tension to reduce the shaking motion to a certain extent
      3. 24 levels adjustable damper -- This allows you the ability to perfectly dial in your coil-overs system. For nice comfortable driving, set damping to full soft. For more spirited driving, set it to 16 clicks. For occasional track days, set it to full stiff.
      4. CNC machined Aluminum  top mounts and lockers-- - excellent strength, and save weight
      5. Heavy Duty Steel Lower Mounts--- Highly Durable & Reliable
      6. Upgraded spring --- more than 600,000 times continuously test to assure its high tensile strength.
      7. All inserts come with fitted long rubber boots--- To protect the damper better and be durable.
      8. With a better-damping setting, you will get better performance and comfort at the same time.
      9. Twin-Tube structure ---provides excellent handling & control characteristics for most driving conditions
      10. Anti-corrosion Finish - Anodized Aluminum And Powder Coated Carbon Steel Parts
      11. Test for the best---Every part was tested on our professional machine before being assembled and tested by our professional racers on the road.
      12. Clean room assembled---maintain a higher level of accuracy and reliability.
      13. Upgraded damper oil---make damping more stable and smooth in a wide temperature range.
