Model | 202M |
Specification | |
decode time | <0.2s |
Communication | Weigand 26 |
Card type | MF1 S50 S70 13.56Mhz |
Induction Distance | 10~18cm |
Power supply | DC12V |
DATA transfer range | Max 80m |
Currency | <100MA |
Working Temperature | 0~70°C |
Working Humidity | Less than 80% |
Warranty | |
Warranty | 24 months |
Physical | |
Dimension (LxWxH mm) | 86*115*18 |
Package | plastic casing &epoxy saturated |
Color | black/white |
Weight (kg) | 0.25 |
Images | |
Overall view: | |
PIN descripiton
Pin | Colour | Description |
1 | Red | DC12V |
2 | Black | GND |
3 | Green | WG data0 |
4 | White | WG data1 |
5 | Yellow | BUZZER |
6 | Blue | LED |
Some special services:
we can provide not only the standard products,but also customized things,for example,
color/Logo/Label/DATA format&package etc,if you think it is necessary!
