Detailed Description: | |
| General | |
| Brand | FCARD |
| Model | FC80 |
| Specification | |
| Response time | <0.2s |
| Communication | Weigand 26 |
| Card type | EM card , EM compatible card ,EM4100\4102 |
| Induction Distance | 10~18cm(max to 35cm,meanwhile a special coil &card should be necessary) |
| Induction Type | EM card |
| Power supply | DC5V |
| Working Temperature | 0~70°C |
| Working Humidity | Less than 80% |
| Warranty | |
| Warranty | 24 months |
| Physical | |
| Dimension (LxWxH mm) | 20*20*5mm(23*23*8mm with epoxy casing) |
| Weight (kg) | 0.01 |
| Pin | Symbol | Description |
| 1 | Buz | To Buzzer's minus pin |
| 2 | LED | To LED's minus pin,the LED will flash while card presented. |
| 3 | WG1 | WG26 data 1 output |
| 4 | WG0 | WG26 data 0 output |
| 5 | +5V | DV 5V power supply |
| 6 | GND | GND |
| 7 | ANT | To coil |
| 8 | ANT | To coil |
About Wiegand
Wiegand 26bits Format Interface
Wiegand 26bits Format Interface comprises of 26bits data including 24 user bits and 2 parity check bits. The 24 user bits correspond to the latter 40 user bits in tags.
Bit | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 20 | 21 | 22 | 23 | 24 | 25 |
PE | D | D | D | D | D | D | D | D | D | D | D | D | D | D | D | D | D | D | D | D | D | D | D | D | PO | |
E | E | E | E | E | E | E | E | E | E | E | E | O | O | O | O | O | O | O | O | O | O | O | O | |||
D40 | D41 | D42 | D43 | D50 | D51 | D52 | D53 | D60 | D61 | D62 | D63 | D70 | D71 | D72 | D73 | D80 | D81 | D82 | D83 | D90 | D91 | D92 | D93 |
1. PE as even parity check bit and PO as odd parity check bit;
2. The bits marked with E go for even parity check and the bits marked with O go for odd parity check;
Wiegand 26bits Format Timing
SYMBOL | DESCRIPTION | VALUE( Typ. ) |
THD | Sending Start Delay | 0.06ms |
TSD | Sending Stop Delay | 2ms |
TDW | Data pulse width | 0.4ms |
TIW | Data pulse interval width | 2ms |
