Board Size

microATX
244W x 244D mm

Processor Supported

AMD EPYC™ 4004 Series Processors
AMD Ryzen™ 7000 Series Processors
Single processor, 5nm technology
TDP up to 170W

Note:
- Recommend to install 170W CPU with liquid cooling kit.
- When installing liquid cooling kit for CPU or GPU, please keep proper airflow for ventilation to prevent heat accumulation.

Socket

1 x AM5

Chipset Description

AMD B650E

Memory Type

4 x DIMM slots
DDR5 memory supported only
Dual channel memory architecture
ECC UDIMM 1Rx8/2Rx8 supported
Non-ECC UDIMM 1Rx8/2Rx8/1Rx16 supported
Total capacity up to 128GB
Memory speed: Up to 5200 MT/s (1DPC), 3600 MT/s (2DPC)

Integrated Network

2 x 1Gb/s LAN ports (2 x Intel® I210-AT)
Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Integrated Video Controller

Integrated in Aspeed® AST2600
- 1 x VGA port

Integrated Audio Controller

N/A

Storage Interface

FCH:
4 x SATA 6Gb/s ports

Support RAID Function

RAID 0/1/10

Expansion Slot

Slot_3: PCIe x16 (Gen5 x16) slot, from CPU
Slot_1: PCIe x4 (Gen4 x4) slot, from FCH

1 x M.2 slot:
- M-key
- PCIe Gen5 x4, from CPU
- Supports 2242/2280 cards

On-Board Connector

1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
5 x System fan headers
1 x USB 2.0 (Type-A)
1 x USB 3.2 Gen1 x2 header
1 x USB 2.0 x2 header
1 x M.2 slot
4 x SATA connectors
1 x Front panel header
1 x Backplane board header
1 x PMBUS connector
1 x IPMB connector
1 x TPM header

Rear I/O Connectors

2 x USB 3.2 Gen1 (Type-A)
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED

TPM

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

OS Driver Supported

EPYC 4004 Series:
Ubuntu 22.04
Ubuntu 24.04
Windows Server 2022

Ryzen 7000 Series:
Windows 10 21H2
Windows 11

Server Management

Aspeed® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

· Dashboard

· HTML5 KVM

· Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)

· Sensor Reading History Data

· FRU Information

· SEL Log in Linear Storage / Circular Storage Policy

· Hardware Inventory

· Fan Profile

· System Firewall

· Power Consumption

· Power Control

· Advanced power capping

· LDAP / AD / RADIUS Support

· Backup & Restore Configuration

· Remote BIOS/BMC/CPLD Update

· Event Log Filter

· User Management

· Media Redirection Settings

· PAM Order Settings

· SSL Settings

· SMTP Settings

PSU Connector

1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector

Operating Properties

Operating temperature: 10°C to 40°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Packaging Bundle

1 x MC13-LE0
1 x I/O shield
1 x Quick start guide
4 x SATA 6Gb/s cables (500mm)

Single Box dimensions: 321 x 308.5 x 78.5 mm
Carton dimensions: 630 x 420 x 345 mm
Quantity: 10 x single boxes in one carton

Bulk Packaging Content

10 x MC13-LE0
10 x I/O shields

Carton dimensions: 609 x 581 x 362 mm
MOQ: 10 PCS MC13-LE0

Ordering Information

Retail: 9MC13LE0MR-000-3*/1*
Bulk: 9MC13LE0NR-000-3*/1*

Part Numbers:

- I/O shield: 12AIO-MC13LE-00R
- SATA cable (500mm)(2 in 1 package): 12CF1-2SAT01-31R
