Heavy Duty Galvanised Wire Rope Clamps DIN 741 U-Bolt Cable Clips 3-14mm
Galvanised steel U-bolt wire rope clamps to DIN 741, matched sizes for 3-14mm rope. Bolt-up fitting secures a loop termination without swaging tools.
✅ Suitable for: Fencing, balustrade wire tensioning, general rigging (3-14mm rope)
Fast UK
Delivery
Delivery
60-Day
Free Returns
Free Returns
Strict Quality
Control
Control
DIN 741 Standard
The recognised standard for U-bolt wire rope clips.
Galvanised Steel
Corrosion resistance in outdoor rigging, fencing and agricultural environments.
Full Rope Range
Eight matched sizes spanning rope diameters from 3mm to 14mm.
Simple Bolt-Up Fitting
U-bolt and grooved saddle clamp the loop shut with two nuts - no swaging tools needed.
Size-Matched by Design
Each clamp grips its intended rope diameter correctly.
Pairs With Thimble
Designed to be paired with a matching wire rope thimble (sold separately).
Reusable Connection
Can be checked and re-tightened after the rope has settled under initial load.
Compact Hardware
Adds minimal bulk to the finished loop.
Technical Specification
| Material | Galvanised Steel |
| Standard | DIN 741 |
| 3mm Rope (Thread/Clamp Length) | M4 / 21mm |
| 5mm Rope (Thread/Clamp Length) | M5 / 23mm |
| 6mm Rope (Thread/Clamp Length) | M5 / 26mm |
| 8mm Rope (Thread/Clamp Length) | M6 / 30mm |
| 10mm Rope (Thread/Clamp Length) | M8 / 34mm |
| 11mm Rope (Thread/Clamp Length) | M8 / 36mm |
| 13mm Rope (Thread/Clamp Length) | M10 / 42mm |
| 14mm Rope (Thread/Clamp Length) | M10 / 44mm |
