Product Type: PTO Clutch |
Replaces: 521988 AM136787 AM137323 AM138730 5219-88 |
  • Crankshaft Diameter: 1" |
  • Ft Lbs Torque: 125 |
  • Pulley Diameter: 5.625" |
  • Rotation: Counterclockwise |
  • Source: Aftermarket

Electric PTO Clutch John Deere AM136787 AM137323 Z225 Z425 Z445 Z465

Replaces Part Numbers & Specifications

OEM PART NUMBERS:
• John Deere: AM136787
• John Deere: AM137323
• John Deere: AM138730
• Warner Electric: 5219-88
• Warner Electric: 5219-225

SPECIFICATIONS:
• Type: Electric PTO Clutch (Power Take Off)
• Crankshaft Diameter: 1"
• Pulley Diameter: 5.625" (5-5/8")
• Overall Height: 4.25" (4-1/4")
• Rotation: Counterclockwise (CCW)
• Belt Width: 1/2" or 5/8"
• Torque: 125 ft-lbs
• Design: Integrated Clutch and Brake
• Connection: Integral Pigtail Wire Harness
• Weight: 11.1 lbs
• Condition: New

FITS JOHN DEERE EZTRAK ZERO TURN MOWERS:
• Z225 - 42" Deck - 18.5 HP Briggs & Stratton V-Twin - Serial No. 0 to 100001 (2007-2012)
• Z425 - 48" Deck - 22 HP Briggs & Stratton V-Twin - Serial No. 040001 to 100000 (2009-2015)
• Z425 - 54" Deck - 22 HP Briggs & Stratton V-Twin - Serial No. 040001 to 100000 (2009-2015)
• Z445 - 48" Deck - 24 HP Kawasaki V-Twin - Serial No. 040001 to 100000 (2009-2015)
• Z445 - 54" Deck - 24 HP Kawasaki V-Twin - Serial No. 040001 to 100000 (2009-2015)
• Z445 - 54" High Capacity Deck - 24 HP Kawasaki V-Twin - Serial No. 040001 to 100000
• Z465 - 62" Deck - 25 HP Kawasaki V-Twin - All Models (2008-2010)

SERIAL NUMBER CROSS-REFERENCE:
• This clutch (AM136787/5219-88) fits LATER serial numbers
• For Z425 SN 0 to 040000 and Z445 SN 0 to 040000 use AM134397/AM141536 (5219-62/5219-87)
• Z225 fits SN 0 to 100001 with this clutch
• Z465 fits all serial numbers with this clutch
• Verify OEM part number and serial number from your original unit before ordering

Product Notice

As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

JOHN DEERE EZTRAK ZERO TURN MOWERS:

Z225:
• John Deere EZtrak Z225 - 42" Deck - 18.5 HP Briggs & Stratton V-Twin - Serial No. 0 to 100001 - 2007, 2008, 2009, 2010, 2011, 2012

Z425:
• John Deere EZtrak Z425 - 48" Deck - 22 HP Briggs & Stratton V-Twin (724cc) - Serial No. 040001 to 100000 - 2009, 2010, 2011, 2012, 2013, 2014, 2015
• John Deere EZtrak Z425 - 54" Deck - 22 HP Briggs & Stratton V-Twin (724cc) - Serial No. 040001 to 100000 - 2009, 2010, 2011, 2012, 2013, 2014, 2015

Z445:
• John Deere EZtrak Z445 - 48" Deck - 24 HP Kawasaki V-Twin (726cc) - Serial No. 040001 to 100000 - 2009, 2010, 2011, 2012, 2013, 2014, 2015
• John Deere EZtrak Z445 - 54" Deck - 24 HP Kawasaki V-Twin (726cc) - Serial No. 040001 to 100000 - 2009, 2010, 2011, 2012, 2013, 2014, 2015
• John Deere EZtrak Z445 - 54" High Capacity Deck - 24 HP Kawasaki V-Twin (726cc) - Serial No. 040001 to 100000

Z465:
• John Deere EZtrak Z465 - 62" Deck - 25 HP Kawasaki V-Twin - All Models - 2008, 2009, 2010

IMPORTANT SERIAL NUMBER NOTES:
• Z225: Fits Serial No. 0 to 100001
• Z425: Fits Serial No. 040001 to 100000 ONLY (for SN 0 to 040000 use AM134397/AM141536)
• Z445: Fits Serial No. 040001 to 100000 ONLY (for SN 0 to 040000 use AM134397/AM141536)
• Z465: Fits All Models
• Verify OEM part number and serial number from your original unit before ordering
