Battery balancer battery equalizer for 2 X 12V lead acid battery 24V battery
Product Image:
Product Description:

the Battery Equalizer is used for the 12V Gel/Flood/AGM Lead Acid Batteries which are connected in series to keep battery voltage balance. When two or more in series connected batteries are in charging/discharging/free status.The battery voltages maybe become different. One battery voltage is high and one is low.The battery equalizer wil equalize/balance the battery voltage when it detect there are 20mV between two batteries. It wil shunt curent from one battery (the higher voltage one) to the other battery (the lower voltage one). Until their battery voltage almost becomes same. This will improve battery's perfomance and extend battery's life time.



Battery equalizer can be used for 24V, 36V, 48V and any other N*12V batery system.

1 pieces for 24V sytem;

2 pieces for 36V sytem;

3 pieces for 48V sytem;



Battery nominal voltage 2*12V
Optimizing current 0~5A
Quiescent current <3mA
Dimension 70*70*27mm
Protection Reverse Polarity Protection
Low Voltage Disconnect 10V





  LED A LED B
U(A)=U(B) Off Off
U(A)>U(B) Flash Off
U(A)<U(B) Off Flash
U(A)<10V On Off
U(B)<10V Off On
U(A/B)<10V On On



Please connect the battery equalizer to battery as following :(please check the pictures)

1.Red cable:Battery B Positive/ +pole

2.Black cable:Battery A negative/ - pole

3.White Cable:Battery B negative pole or Battery A Positive pole(the pole which connected Battery A and Battery B in series )
