Longer steel braided brake line / steel flexible brake hoses, including material certificate, for conversion to larger brake system for example Brembo 4-6 piston brake caliper installed into Porsche or TTRS.

Suitable for the following models:

• Golf MK5 / MK6 / MK7
• Seat
• Audi A3 / S3

Advantages compared to original brake lines:

• no loss of pressure when braking. Exact pressure point
• easy assembly. The original line is simply replaced by the braided steel line
• no swelling as with rubber lines
• cost savings, because the braided steel lines do not need to be changed every 3 or 5 years
• shorter braking
• protection against the rodents
• incl. parts certificate for problem-free registration
• great optics

Technical data:

• length: 42 cm
• connection 1 M10x1 external thread bent
• connection 2 M10x1 internal thread straight
• sealing 90° connection: E and F. Our fittings are so-called hybrid, which means that every connection fits no matter whether concave and convex

Delivery:

• 2x steel braided brake lines for VW Golf MK5 / MK6 / MK7 Audi A3, etc
• material certificate

We also manufacture according to desired dimensions. With our  (link not available) , you can configure your steel braided brake line, according to your wishes. (Length, color and connections)

• Einfache TÜV Eintragung
• Qualität Made in Germany
• Faire Preise ohne Zwischenhandel, du kaufst direkt beim Hersteller und Enwickler des Produktes
• Weltweit Nr 1 in Sachen Tuning Adapter
• 15 Jahre Expertenwissen
• 10 Jahre Garantie

• Does the steel braided brake line also fit other vehicles?

• Yes, the brake line can be used in many other vehicles as well. Since almost all car manufacturers use the same size of thread for brake line fittings. Often the only difference is the concave or convex sealing surface. Our fittings are so-called hermaphrodite, which means that each fitting is suitable, concave (valley) and convex (mountain). All you have to do is measure the length and find out the thread size of the fitting you want for your line. So you can see if the line is suitable. You can find the exact details of the brake line in the product description under the technical data.

• There were 2 lens seals supplied with the steel faux lines. Where exactly are these installed?

• the lens seals are always included with the orders. They are used to balance the cone, depending on the cone of the steel tube, see picture attached. With flare F you do not need the lens seals, with flare E they must be placed in the internal threads. The direction, which way around, does not matter.
