Voltage dc 24V
Correction rollers take adjustment action to facilitate the user to replace the tube avoid clipping and breaking the tube due to lack of experience
Ball bearings in the wheel frame, silent, long life time
Stainless steel screws, rust corrosion resistance
Set the card slot to prevent deviation correction, pump damage
Motor: DC motor
DC motor current: 0.5-1.4A
Working environment: 0-40, relative humidity, 80%
Medium flow: the flow direction of this pump depends on the positive and negative connections
Flow range: 0 - 400ml/min
Tube: inner diameter * outer diameter (6.8mm * 10mm)
wall thickness: 1.6mm, the maximum diameter: 10mm
Product weight: 0.6Kg
Tube material: transparent silicone tube
Roller type: ball bearing
Product characteristic:
Pump cover: hand twist screws, quick disassemble convenient tube replacement
Can be equipped with constant speed DC deceleration motor, stepper motor (adjustable speed)and synchronous motor, long motor life and low noise stepper motor
Shell material: PC
Rolling wheel: POM
