Analog Devices ADR4540BRZ Voltage Reference 4.096V ±0.02% 8-Pin SOIC
You get 1 Voltage Reference IC- BMUK Part # :-802-3907
- BrandAnalog Devices
- Mfr. Part No.ADR4540BRZ
Product Details
Voltage Reference, 3.0V to 4.5V, Analog Devices
Voltage References, Analog Devices
Precison Fixed and Adjustable Voltage Reference ICs utilsing series, shunt or series/shunt topologies and available in both through-hole and surface mount packages. Voltage References are available with initial accuracies of ±0.02 to ±2%.
Specifications
| Nominal Voltage | 4.096V | |
| Package Type | SOIC | |
| Reference Type | Precision | |
| Initial Accuracy | ±0.02% | |
| Mounting Type | Surface Mount | |
| Topology | Series | |
| Maximum Output Current | +10mA | |
| Maximum Input Voltage | 15 V | |
| Pin Count | 8 | |
| Line Regulation | 10 ppm/V | |
| Load Regulation | 120 ppm/mA | |
| Dimensions | 5 x 4 x 1.5mm | |
| Height | 1.5mm | |
| Minimum Operating Temperature | -40 °C | |
| Maximum Operating Temperature | +125 °C | |
| Length | 5mm | |
| Width | 4mm |
View the full DATA SHEET here
