The MS-2015 AC power distribution
unit offers 15 amp, 120 volt capacity in a rack mount cabinet. Fixed mounting
flanges offer a solid rack mount installation. Uses only (1) rack space
(1U) when installed in any 19 inch rack. All-steel housing with (10) rear-facing
outlets and (10) front-facing outlets measures only 4.5 inches in depth.
Unfiltered electrical pass-through and a lighted switch with latching safety
cover, prevents risk of accidental turn-off. Ideal for distributing alternate
waveform UPS or generator power in rack enclosures, network closets and
more. Includes 15 foot AC power cord, 15 amp circuit breaker and a
Limited Lifetime
warranty.
|
SHIPPING
We ship using... |
 or or |
FREE Shipping
to the Continental US Only |
 |
|
|
Model Number |
MS-2015 |
| Overall Length: |
19 in (with rack
mount) |
| Number of
Receptacles: |
20 (10 Front/10 Rear) |
| Cord Length: |
15 ft |
| Mounting
Type: |
Flange (rack mounting
screws not provided) |
| Approval: |
UL Approved |
| Maximum Rating: |
60Hz, 15A, 120V |
| Unit Color: |
Black |
| Housing: |
Steel |
| Type of Receptacle: |
NEMA 5-15R (15A 125V)
Black Outlet |
| Circuit Breaker: |
15 Amp |
| Cord Type: |
14/3 SJT |
| Type of Plug: |
NEMA 5-15P (15A 125V)
Molded on Plug |
| Color of
Cord: |
Black |
| Cord Location: |
Exits the rear of
the housing |
| Switch: |
Lighted with locking
cover |
| Spacing: |
Equally, approximately
1.25 in on center |
| Dimensions
(LxDxH): |
17.25 x 4.25 x 1.75
in (*19 in with Rack Ears) |
| Weight: |
5.1 lb (Unit only)
/ 5.5 lb (Net) |
|
