Digital AC DC Magnetometer Magnetic Strength Tester Gauss Meter Tesla Meter
Note: Battery not Included During The Shipping !!!
Introduction:
- The item is a portable and multifunctional magnetic field measuring instrument,equipped with a Hall sensor with high sensitivity and low drift.
- It is applied for measuring the flux density of DC constant magnetic field and AC magnetic field.
Features:
- Range: 2mT ~ 3000 mT.
- Accuracy: class 1 or 2.
- Switching AC or DC mode
- Unit switch: G, mT, A/m.
- N/S polarity display.
- Relative measurement mode.
- Max. hold function.
- Alarm of exceeding the upper / lower limit.
- Supporting backlight.
- Battery remaining power display.
- Axial, radial probe are optional.
- USB interface.
- Optional magnetic shielding cavity.
Application:
Specifications:
|
Range |
30 mT |
300 mT |
3000 mT[1] |
|
|
Resolution |
1 μT |
10 μT |
0.1 mT |
|
|
Measuring Range |
2mT~3000mT |
|||
|
Accuracy |
Class 1 |
DC:±1%,AC:±5% |
||
|
Frequency Range |
DC,40Hz~500Hz |
|||
|
Temperature Coefficient |
± 0.1% / K |
|||
|
Zero Drift |
± 0.1 mT/h |
|||
|
Display Digit |
5 |
|||
|
Remark |
[1] Calibration only covers 2.5T |
|||
|
Power Supply |
3 AA batteries or USB charging (not Included) |
|
Temperature Performance |
Operating temperature: 0~50℃;
Storage temperature: -20°C~70°C |
|
Humidity Performance |
Operating humidity: 40%~80% R·H, non-condensing
Storage humidity: <95% R·H, non-condensing |
|
Weight |
About 350 g |
|
Interface |
Hall probe input interface, USB interface |
|
Overall Dimensions |
90mm(W) ×40 mm(D) × 165 mm(H) |
Ordering Information:
|
Optional Radial or Axial Hall Probe |
|||
|
TM1100 Hall probe
(Standard Accessory) |
Radial Hall probe |
|
|
|
TM1110 Hall probe
(Optional Accessory) |
Axial Hall probe |
|
|
|
Standard configuration is Radial Hall probe, also can choose Axial Hall probe.
Note: The users should indicate the probe in the order contract. |
|||
