Product number:
DYCP-31BN
use
Suitable for identification, isolation, preparation of DNA, and determination of molecular weight
Characteristics
* Transparent upper cover open hole design, easy to dissipate heat, easy to observe
* Gel tray with fluorescent ruler for easy observation
*Highly flexible wire, open cover and power off to ensure safety
*Polycarbonate injection molding, no leakage
* Bridge design, saving buffer
*Removable electrode holder and electrode tip for easy cleaning and maintenance
Dimensions
(L × W × H): 197 × 96 × 100mm
Gel plate specification
(L × W): 60 × 60mm
Sample grid
6 teeth, 8 teeth, 1.5mm thick, 11 teeth, 1.0mm thick, 1.5mm thick
Total buffer capacity
120ml
configuration list
Number / Name / Standard Quantity
413-1200/ Electrophoresis (main body) / 1
413-1203/ Electrophoresis instrument (top cover) / 1
141-3122N/1.5mm6 tooth / 8 tooth sample grid / 1
141-3121N/1.0mm / 1.5mm11 tooth sample Grid / 1
143-3145/ glue machine / 1
143-3143/ gel tray/2
144-0011/ Electrophoresis wire / 1 pair
DYCP-31CN
use
Suitable for identification, isolation, preparation of DNA, and determination of molecular weight
Characteristics
*Special gluer mold molding, easy to make glue
* Transparent upper cover open hole design, easy to dissipate heat, easy to observe
* Gel tray with fluorescent ruler for easy observation
*Highly flexible wire, open cover and power off to ensure safety
*Polycarbonate injection molding, no leakage
* Bridge design, saving buffer
* High temperature resistance, no deformation
* Limit function, accurate operation
*Removable electrode holder and electrode tip for easy cleaning and maintenance
Dimensions
(L × W × H): 270 × 115 × 110mm
Gel plate specification
(L × W): 100 × 70mm
Sample grid
8, 15 teeth, 1.0, 1.5mm thick
Total buffer capacity
260ml
configuration list
Number / Name / Standard Quantity
413-1302/ Electrophoresis apparatus (main body) / 1
413-1303/ Electrophoresis apparatus (top cover) / 1
141-3135/1.0mm8 tooth / 15 tooth sample grid / 1
141-3136/1.5mm8 teeth / 15 tooth sample grid / 1
143-3132/ glue machine / 1
143-3131/ Gel tray (100*70mm)/2
144-0011/ Electrophoresis wire / 1 pair
DYCP-31DN
use
Suitable for identification, isolation, preparation of DNA, and determination of molecular weight
Characteristics
*Molding machine mold molding, can make four different sizes of glue
* Transparent upper cover open hole design, easy to dissipate heat, easy to observe
* Gel tray with fluorescent ruler for easy observation
*Highly flexible wire, open cover and power off to ensure safety
*Polycarbonate injection molding, no leakage
* Bridge design, saving buffer
* High temperature resistance, no deformation
* Limit function, accurate operation
*Removable electrode holder and electrode tip for easy cleaning and maintenance
Dimensions
(L × W × H): 310 × 150 × 120mm
Gel plate specification
(L × W): large glue 120 × 120mm; wide glue 60 × 120mm;
Long glue 120×60mm; small glue 60 × 60mm
Sample grid
2+3 teeth (2.0mm thick), 6+13 teeth,
8+18 teeth (1.5mm thick),
11+25 teeth (1.0mm thick) can be loaded with a gun
Total buffer capacity
650ml
configuration list
Number / Name / Standard Quantity
413-1402/ Electrophoresis apparatus (main body) / 1
413-1403/ Electrophoresis apparatus (top cover) / 1
141-3143/1.0mm25 tooth / 11 tooth sample grid / 4
141-3141/1.5mm13 tooth / 6 tooth sample grid / 1
141-3142/1.5mm18 tooth / 8 tooth sample grid / 1
141-3144/2.0mm3 tooth / tooth sample / 1
143-3146/ glue machine / 1
143-3143/60mm*60mm gel tray/2
143-3142/60mm*120mm gel tray / 1
143-3141/120mm*60mm gel tray / 1
143-3144/120mm*120mm gel tray / 1
144-0011/ Electrophoresis wire / 1 pair
