application with GPON MAC
function.
• SC/UPC receptacle SFP with GPON ONU MAC inside, “Plug-and-play” via auto-discovery and configuration
• 1310nm DFB burst mode transmitter, 1490nm TIA continuous mode receiver
• Single 3.3V power supply
• Digital diagnostic monitor interface compatible with SFF-8472
• SFP MSA compliance
• Low EMI and excellent ESD protection
• Class I laser safety standard IEC-60825 compliant
• RoHS compliance
• EPON ONU compatible
• Complies with SFP Multi-Source Agreement (MSA) SFF-8074i
• Complies with ITUT-T G.984.2, G.984.2 Amendment 1
• Complies with ITUT G.988 ONU management and control interface (OMCI) specification
Description
V06 Version is without DDM function
V08 Version is with DDM function
XPON 1.25G/2.5G SFP ONU Stick With MAC SC Connector DDM pon module
XPON=XPON 1.25G/2.5G ,It can use for Epon and Gpon at the same time
Connector:SC/APC
Key Features
1. 1490 nm wavelength downstream,1310 nm wavelength upstream
2. GPON： 2.5Gb/s line rate downstream, 1.25 Gb/s line rate upstream
EPON： 1.25Gb/s line rate downstream, 1.25 Gb/s line rate upstream
3.Complies with SFP Multi-Source Agreement (MSA) SFF-8074i
4. Digital Diagnostic Monitor（DDM） interface compatible with SFF-8472
5. Complies with ITU-T G.984.2, G.984.2 Amendment 1
6. Complies with ITU-T G.988 ONU management and control interface (OMCI)
7.Class I laser safety standard IEC-60825 compliant
8.RoHS compliance
Advantage
Small Form-Factor Pluggable (SFP)
Easy to install
Low power consumption
Technical Parameter
|
Item |
HSGQ-XPON-STICK |
|
Interface |
1*PON |
|
PON |
Physical Interface: PON Port |
|
type: SC/UPC ( if you need SC/APC ,Please leave message ) |
|
|
Size |
8.2mm x 6.8mm x 75mm |
|
weight |
＜19g |
|
Environment |
Operating temperature:-40°C~85°C （I Temp） |
|
Operating temperature:0°C~70°C （C Temp） |
|
|
Storage humidity:5%~95% (non-condensing) |
|
|
Power Supply |
3.3V |
|
Power Consumption |
＜2.5W |
|
PON Function |
GPON/EPON adaptive |
|
Mode |
SFU |
|
Optionally support some functions of HGU(DCHP/PPPoE/NAT) |
|
|
Configure MAC address |
Support |
|
Configure SN |
Support |
|
Configure Vendor ID |
Support |
|
Configure PVID |
Support |
|
DDMI |
Support |
|
Management |
Http/telent/SSH/TR069 |
|
SFP MSA Standard |
Support |
|
VLAN |
VLAN transport transmission |
|
VLAN swtich function |
It is a 'PON on a Stick*' that an entire FTTH ONU in a slightly oversized SFP.lt can be plugged into networking equipment.
Allowing the data interfaces on a switch, router, etc. to be customized for different fiber environ-ments and distance requirements.
1GE ONT software version is SFU default,You dont need to do any configuration via ont web.Support port mode of VLAN configuration and u could configure port vlan of ont via olt.After reset ont,there is no wan connection.
