PRODUCT DESCRIPTION
A robust 48V/60V/72V gasoline‑powered alternator designed for off‑grid power generation, backup electricity, or mobile applications. Equipped with a 210‑240cc 4‑stroke engine and a high‑efficiency 54‑pole pure‑copper generator, it delivers stable AC output with selectable voltage for various power needs.
TECHNICAL SPECIFICATIONS
Output Voltage: 48 V / 60 V / 72 V AC (selectable)
Power Output: 3 – 10 kW (depending on engine load and configuration)
Engine Model: 170/225F 4‑stroke gasoline engine
Displacement: 210 cc / 240 cc
Rated Speed: 3300 RPM
Generator Type: 54‑pole pure‑copper winding alternator
Starting Method: Electric start (battery‑assisted)
Fuel Type: 92# unleaded gasoline
Weight: 20 kg (approx. 44 lbs)
Cooling: Air‑cooled
Dimensions: (To be confirmed with manufacturer)
KEY FEATURES & BENEFITS
TRIPLE VOLTAGE OUTPUT: Selectable 48V, 60V, or 72V AC output provides flexibility for charging battery banks, running AC devices, or powering specific equipment.
HIGH‑EFFICIENCY GENERATOR: 54‑pole pure‑copper windings ensure high energy conversion efficiency, low heat loss, and durable performance under load.
POWERFUL & RELIABLE ENGINE: 4‑stroke 210/240cc gasoline engine offers steady power, lower emissions, and easier maintenance compared to 2‑stroke designs.
ELECTRIC START CONVENIENCE: Battery‑assisted electric start enables quick, effortless ignition – no manual pulling required.
PORTABLE & COMPACT: At ~20 kg, it is relatively portable for a generator of this power class, suitable for job sites, camping, or emergency backup.
VERSATILE APPLICATIONS: Ideal for off‑grid cabins, construction sites, agricultural use, emergency power, RV/vanlife, and remote workshops.
IMPORTANT SAFETY & OPERATIONAL NOTES
Voltage Selection: Ensure the selected output voltage matches your device/battery system requirements before connecting.
Ventilation Required: Always operate in a well‑ventilated outdoor or highly ventilated area to prevent carbon monoxide poisoning.
Fuel Safety: Use only 92# unleaded gasoline. Store fuel in approved containers away from ignition sources.
Load Management: Do not exceed the maximum continuous load rating (likely ~6‑8 kW continuous, 10 kW peak). Check manufacturer specifications.
Maintenance: Perform regular oil changes, air filter cleaning, and spark plug inspection as per the engine manual.
Electrical Safety: Use appropriately rated cables and connectors. Ground the generator if required for your application.
TYPICAL APPLICATIONS
Charging 48V/60V/72V battery banks for solar/wind hybrid systems
Powering AC tools and lighting on remote job sites
Emergency backup power for homes or communications equipment
Providing electricity for camping, events, or food trucks
Agricultural irrigation pumps or farm equipment
PACKAGE INCLUDES
(May vary – confirm with seller)
1 × Gasoline Alternator (48V/60V/72V)
1 × Battery for electric start (may require separate purchase)
1 × Tool kit / basic accessories
