Package Include:
1 X 4-Row Aluminum Radiator
1 X Radiator Cap
1 X Aluminum Shroud
2X 12" Fans (Includes mounting kits)
Application:
For Ford F-Series F100 F150 F250 F350 F450 Bronco V8 Engine 1983-1997
For 1985-96 Ford Bronco Radiator 5.0L & 5.8L V8 Engine
For 1985-96 Ford F150 Truck Radiator 5.0L & 5.8L V8 Engine
For 1985-97 Ford F250 Truck Radiator 5.0L& 5.8L &7.5L V8 Engine
For 1985-97 Ford F350 Truck Radiator 5.0L&5.8L&7.5L V8 Engine
For 1988-97 Ford F450 Truck Radiator 7.5L V8 Engine
ONLY FOR V8 ENGINE some model is L6 Engine
Radiator Configuration:
High Performance Racing Spec.4-Row of tubes Core Racing Design
Core Dimensions: 18-3/8" High x 27-1/2" Wide
Overall Dimensions: 22-1/2" High x 37-1/4" Wide
Upper Inlet: 1-3/4" located on the passenger side.
Lower Outlet: 1-3/4" located on the driver side.
Transmission Cooler: Included (1/8-27NPT)
Please Check the Size Before You Buy!
Aluminum Shroud and Fans:
The New Design fan and the fan shroud effectively drive the heat over and out the engine compartment rather than thrusting it into the front of the engine. The fan shroud basically houses the fan blades securing it in place and keeping it from damaging the other engine components that may disturb the smooth and even operation of the engine. With excellent operating temperature management, allowable levels of engine temperature are stabilized. Investing in proper maintenance though will considerably benefit the ride and driving quality in maintaining the ideal working conditions of the engine.
1.Shuttered design fan shroud to guaranteed airflow passes high efficiently.Make your engine bay perfect!
2. S blade fans, Push or Pull Type design,lightweight Plastic Durable Material.
FAN Specification:
Maximum Fan CFM: 1730 cfm
Fan Diameter (in): 12.050”
Thickness (in): 2.500”
Number of Blades: 10 S-Type blades
Blade Material: Plastic
Amp Draw: 12.70 amps
Includes the Mounting Tabs for an Easy Zip Tie Installation
Thermostat Kit:
Work with any 12 volt system.
Universal fit for any automotive vehicle and electric fan.
Activates by grounding electric fans at preset temperature.
185'F turn-on temperature, 165'F turn-off temperature.
Probe typically threads into radiator, water outlet or manifold.
Thermostat Relay Kit Instructions：
RED + connect directly to battery.
WHITE wire to ignition switch power source.
BLACK goes to thermos switch.
BLUE wire goes to the Fans.
Description:
Our Aluminum is an Al-Mg alloy with good corrosion resistance, excellent reliability and cold workability and strength. It is widely used in the manufacture of aircraft fuel tanks, oil pipes, and sheet metal parts of transportation vehicles and ships, hardware products, and electrical-appliance casings.
This Aluminum Radiator is designed to provide maximum cooling efficiency to prevent premature engine failure. Its light-weight, and high-heat transferring aluminum features a tube and fin design that, dramatically increases surface area that enables the heat to dissipate more efficiently. This Aluminum Radiator is at least 30%-45% more efficient than stock ones. Most importantly, it has a much higher capacity for coolant than stock ones, which means that your cooling system will be more efficient and will be more resistant to temperature surges in racing applications.
