Features:
HIGH PRECISION & RIGID CONSTRUCTION: Machined from solid aluminum alloy (not cast) ensuring exceptional rigidity and minimal vibration for improved accuracy. The spindle housing features a reinforced steel bushing for enhanced durability and precision
CROSS SLIDE TABLE (X-Y AXIS): Equipped with a precise cross slide table providing 115mm (X) and 95mm (Y) travel for accurate positioning of your workpiece during milling or drilling operations
ADJUSTABLE DEPTH STOP: Features a convenient depth limiting function (Z-axis stop), allowing for consistent and repeatable drilling depths – essential for production work
PRECISION MOVEMENT SYSTEM: Utilizes 12mm zero-backlash linear guide rails and 8mm stainless steel lead screws (1mm pitch) with special anti-backlash nuts on all axes for smooth, precise, and backlash-free operation
VERSATILE ER11 SPINDLE: The unpowered spindle accepts ER11 collets (not included), allowing you to use a wide range of drill bits and milling tools securely. Note: A drill chuck typically requires an additional MT2 or JT adaptor
VARIABLE SPEED CONTROL: The 120W motor offers a speed range from 0 to 2000 RPM, adjustable to suit different materials and cutting tools.
COMPACT & PORTABLE: Its small footprint (approx. 300x300x350mm) and manageable weight (11kg) make it ideal for benchtop use in home workshops, studios, or labs
UNIVERSAL VOLTAGE: AC100-240V input means it can be used safely anywhere in the world with the appropriate plug adapter
Specifications:
Name: Bench Top Drill Mill Machine
Power Input: AC100-240V, 50/60Hz
Motor Power: 120W
Spindle Speed: 0-2000RPM (Variable)
Spindle Taper: ER11 Collet
Max. Drilling Capacity (Steel): 7mm
Quill Travel (Spindle Stroke): 28mm
Table Travel (X): 115mm
Table Travel (Y): 95mm
Head Travel (Z): 125mm
Worktable Size (LxWxT): 270*93*20mm
Linear Guides: 12mm Zero-Backlash Type
Lead Screws: 8mm Stainless Steel, 1mm Pitch
Overall Dimensions (approx.): 300*300*350mm
Net Weight: 11kg
Shipping Weight: 17kg
Package includes:
1 x Mini Bench Drill Mill Machine
