KEY FEATURES & BENEFITS
ADVANCED TOUCH SCREEN SYSTEM: The touch screen operating system is a free and open source for the Linux, using a quad-core high-performance processor, with a main frequency of up to 1.5GHz, extremely fast response and smooth operation.
INTUITIVE INTERFACE: Flat interface design: simple software interface appearance with guided scrolling prompt and friendly interaction.
HIGH-QUALITY DISPLAY: 5-inch IPS high-definition capacitive touch screen: a display resolution of 800x480, delicate and colorful display, 180 degrees visible angle.
SMART INPUT METHODS: The market's exclusive double spelling smart input method: support various input modes like predictive typing in Chinese and English, handwriting input, Wubi entry, Cangie input, making editing more efficient. The corresponding language input method can be automatically switched according to the system language.
EASY GRAPHIC IMPORT: Support direct import of pictures in various formats: bmp, jpg, png, and any graphic element can be resized by dragging and scaling, eliminating the tedious operation of computer conversion. Unique font management function: users can import personal favorite fonts.
VERSATILE PRINTING CONTENTS: Various printing contents: contents like the text, date, symbol, LOGO image, two-dimensional code, bar code, etc. can be printed.
MULTI-LANGUAGE SUPPORT: One-click switch languages: more than 20 languages supporting (including corresponding language input methods), and support for any language customization.
EASY UPDATES & MAINTENANCE: Software support USB flash disk update, continuous maintenance optimization. Under electrified, the ink cartridge can be plugged and unplugged freely.
MACHINE SPECIFICATIONS
| Parameter | Specification |
|---|---|
| Model | FRP-810II |
| Voltage (V/Hz) | AC 220/50 / 110/60 |
| Motor Power (W) | 50/100 |
| Sealing Power (W) | 300W x 2 |
| Sealing Speed | 0-16 m/min |
| Sealing Width | 10 mm |
| Temperature Range | 0-300ºC (Adjustable) |
| Distance (Sealing Center to Conveyor) | 200-320 mm |
| Max. Conveyor Load | ≤10 kg |
| External Dimensions | 954 x 400 x 548 mm (37.6" x 15.7" x 21.6") |
| Net Weight | 40 kg (88.2 lbs) |
INKJET PRINTER SPECIFICATIONS
| Parameter | Specification |
|---|---|
| Operation System | Linux |
| Touch Screen | 5 Inch Capacitance Screen, 800x480 Resolution |
| Processor | Quad-core High-performance, Max. 1.5GHz |
| Internal Memory | 1G+4G |
| Print Head | TU2.5 Thermal Foaming Nozzle (TIJ2.5) |
| Print Font Height | 1.5-12.7 mm |
| Printing Length | Unlimited |
| Max. Printing Lines | 6 lines |
| Ink Type & Capacity | Oiliness / 42ml |
| Ink Color Options | Black (standard), Red, Green, Blue, Yellow, White, Transparent |
| Printing Volume per Cartridge | About 200,000 prints (reference: 4mm x 30mm) |
| Content Storage | Store 200 bars (individual count storage) |
| External Terminal | USB / RS232 Serial / WIFI |
| Online Operation | Optional (1 host can control 1+N units) |
| Printing Material | Suitable for Any Composite Film Material (special ink for special materials) |
PRINTABLE CONTENT
Text: Chinese, English, Digital, Symbols
Graphics: Support any image without conversion format (bmp, jpg, png)
Barcodes: QR Code, Bar Code (custom content, real-time variable)
Variables: Variable Date, Variable Count, Variable QR Code (real-time)
LANGUAGES SUPPORTED
| Language Options (Partial List) |
|---|
| Chinese, English, Arabic, Turkish |
| Spanish, Portuguese, Korean, Russian |
| Support customization for any language |
PACKAGE INCLUDES
(Note: Package list not provided – typical inclusions for reference)
1 x FRP-810II Inkjet Printer & Band Sealer Combo
