Product Features：
Blade life up to 48,000 times
Typical cutting angle ≤0.5 degree
Tungsten steel blade, wear resistance,high hardness, corrosion resistance
Traditional bench top design, simple andeasy to use
Double fixture design, suitable for various optical fibers of 250~3.0mm
High-precision CNC machining and forming, excellent texture
Product Parameter：
Fiber Meterial：Single fiber
Cladding Diameter：125μm
Cleaved Length：Single fiber: 8~20mm / Ribbon fiber: 10mm
Applicable Fiber Cable：Single fiber: 250μm, 900μm, 3.0mm
Flat cable / Ribbon fiber: 2 to 12 fiber cable
Typical Cleaved Angle：Less than 0.5 Degrees ①
Typical Blade Life：Total 48,000 fiber cleaves （replaceable） ②
Off-cut Collector：Pre-fitted
Type of Offcut Bin：Manual
Auto Return：Pre-fitted
Dimension / Weight：63W *77D*63H(mm) / 335g
① The fiber cleave angle changes by operating environment
② Blade life changes by operating environment
