Ebike 36V 48V 52V 1500W 45A 3-Mode Sine Wave Controller With EN06/SW900/UKC1 Display
Very important Notice:
This controller can only work without display or with our display, please never use it with your own display (because program is different)
Why 3-mode Controller?
Support Hall Sensor Mode (Sine Wave Mode)
Support Non-Hall Mode (If your motor hall sensor burned or not match, controller will still work in square wave mode)
Support 60-120 degree motor hall sensor adaptive recognition.
Self-learning Function: Even wrong 3-phase combination between motor and controller, doesn’t matter, above self-learning process can correct it!
Parts Including:
1. 15 MOSFET 45A 36V, 48V, 52V Universal Voltage 1200W-1800W Intelligent 3-mode Sine Wave Controller
2. EN06 Display or SW900 Display or UKC1 Colorful Display
Advantage:
1. Sine Wave Controller which support 3-mode (hall sensor mode, non-hall mode, self-learning) and smart match with each motor through self-learning, works with high efficiency, less noise, and lower energy consumption, which makes your electric vehicles or electric motorcycles more comfortable and easier to control, give you best pedal experience
2. Universal Input Voltage Range: 36V/48V/52V
3. Work with or without display
4. Parameter setting via display
5. All protection make it long life and safe: over/under voltage, over current, over load, over heating, anti-runaway, locked-motor protection
6. Multi functions: Work with hall sensor mode or non-hall mode, smart match with different motor, 5//7/9-speed level for throttle and PAS, Current limit, Speed limit, Reverse, Push Assistant, Anti-thief, Regenerative Braking (different level), Electric Braking and etc.
7. Best heat sinking with Aluminium Case
8. Black anodized Aluminium Controller Case against scratch
Technical Data:
General Specification:
1. Rated Power: 36V 810W/ 48V 1080W/ 52V 1170W
2. Peak Power: 36V 1620W/ 48V 2160W/ 52V 2340W
3. Brake: Low Voltage Brake
4. Alarm: Low Voltage Alarm
5. Rotor Position Detecting Method: Hall sensor
6. Size: 212x86.5x48.5mm
7. Net Weight: 610g
8. Waterproof Grade: IP65
FAQ:
1. How shall I match my motor for first time use? (Very Important)
(Please check Controller Connection Diagram and Manual, Page 1)
1). Lift your motor wheel off ground (Very Important)
2). If you connect with display, please make sure PAS/Throttle Speed Level is at any level more than 0 level
3). Connect Self-learning plug 6-8 seconds
4). You will see motor wheel rotate slowly
5). Please check whether rotation direction is correct
(a). If correct direction, then keep 6-8 seconds, then disconnect
(b). If reverse direction, then disconnect and plug again till get correct rotation direction, then keep 6-8 seconds, then disconnect
6). Motor and Controller Pairing finished!
2. Can I use this controller without display?
Yes, you can use this controller without display, just need to connect jumper connector (Please check Controller Connection Diagram and Manual, Page 4, point No.3)
3. How can I limit speed?
In some countries, below 25km/h speed is required on road, you can switch on/off speed limit function by connecting a simple switch to controller speed limit plug, or you can even connect jumper connector to always limit speed (Please check Controller Connection Diagram and Manual, Page 6-7, point No.8)
4. Password for enter "Advance Setting"
1801
