eBike Motorcycle 72V 45AH Rectangle Battery for Max 72V 100A 5000W-8000W Power
Parts included:
72V 45AH Rectangle A Grade 21700 Cell Lithium Battery;
84V 6A/10A Charger;
Discharge Plug: QS8 Female, Charge Plug: Linko Female Plug;
Discharge Extension Cable: QS8 Male plug----- "O" Rings;
Please use this battery maximal for 72V 7200W (Max 72V 100A Controller)
| Specification: | |
| Battery Model | 72V 45AH |
| Nominal Capacity (AH) | 45Ah |
| Nominal Voltage (V) | 72V |
| Source Resistance (mΩ） | <40 |
| Cell Specification | 3.7V 4500mAH 3C Powerful Cell (A Grade, Brand New) |
| Cell Combination | 20-series, 10-parallels |
| Cell Size | 21700 Cylinder Cell Diameter: 18mm, Height: 65mm |
| Cell Quantity (parallel*series) | 200pcs |
| Discharge Cutoff Voltage (V) | 60 +/- 1V |
| Charge Cutoff Voltage (V) | 84V |
| Rated Discharge Current (A) | 45A |
| Maximum Continuous Discharge Current (A) | 130A (Limited by BMS) |
| Maximum Continuous Charge Current (A) | 22A |
| Charge Mode | CC/CV |
| Standard Charge Current (A) | 6A |
| Charge Time under Standard Charge Current (Hours) | 9h |
| Fast Charge Current (A) | 10A |
| Charge Time under Fast Charge Current (Hours) | 5.4h |
| Charge Temperature Range | 0 - 55 ℃ |
| Discharge Temperature Range | -20 - 60 ℃ |
| Battery Size |
475*242*95mm |
| Charging Cycles | > 1000 cycling times |
| Battery Net Weight | 17kgs |
| Battery Gross Weight(include charger and packing) | 21kgs |
| Battery Application | For less than 72V 7200W Motor (Max 72V 100A Controller) |
