This SW102 display just for Bafang BBS01 BBS02 BBSHD Mid Drive Motor.

At present, this display does not have USB,bluetooth function and APP. If the bluetooth function is needed, it can only be customized with a batch order.

1. Handlebar for Holding:Ø 22.2mm

2. Display Cable Length:50cm including connector.

3. Display size:6.3 * 2.3 cm

CONNECTOR

5 Pin Female Base connector

Package size: 75mm × 47mm × 35mm

Weight:about 31g

Fixed size:Ø 22.2mm handle bar

Supply:24V/36V/48V

Current :12mA/36V for working current

Protocol: UART

Screen type: 1.3''OLED

Materaial:ABS+PC with special particles

Waterproof: IP65

Certification:CE/ROHS

Function: PAS Level/Speed/TRIP/ODO/Light status/Battery Indicator/Error Alarm/Walk etc
