SP-12 Solar Submersible Pump High Head 70m Deep Well Pump DC Electric 24V Small Irrigation Suction Water Pump
Introduction:

This solar powered submersible pump can offer a solution to your remote water needs. It designed to be used with solar panels and 24v battery systems. This means Easy Hookup to most any existing solar panels or wind generator systems. It can be used with or without components such as voltage  controllers. This pump can be used for livestock watering, irrigation, ponds, remote homes and cabins. Unique water blocked cable connector is impervious to water leakage and condensation problems preventing water-wicking.

Specification:

Pump Design Positive Displacement 3 Chamber Diaphragm Pump

Motor Permanent Magnet, Thermally Protected

Voltage 12/24VDC Nominal

Wattage 120W

Amps 4.0A Maximum

F rate 1.6 GPM (6 LPM)

Internal Bypass 105-110PSI Max.(7.2-7.5 Bars)

Maximum Lift 230 feet Maximum (70 Meters)

Maximum Submersion 100 Feet Maximum (30 meters)

Outlet Port 1/2'' (12.7mm) Barbed Fitting

Inlet: 50Mesh Stainless Seel Screen

Materials High Strength Engineered Plastics,Stainless Steel Fasteners

Typical Applications Potable Water Well Pump
