PRO-HY8.4B 8" Hybrid Mid-Range Car Audio Loudspeaker with 1" VC Built-In Compression Driver Horn, 500W Max 250W RMS 4 Ohms (1 Speaker)

  • This high powered pro audio mega speaker combines both a 8" high volume midrange speaker that also has a high wattage driver attached to the rear to give you a full range of frequencies at an amazingly loud volume.
  • Hybrid design combines high wattage midrange and driver together in one beautiful frame.
  • High volume 8" and 1" driver rated at 250W RMS and 500W max for crazy loud volume in a full range of frequencies.
  • Water resistant cone to help battle elements and moisture making them great for motorcycles, boats, and regular vehicles too!
  • NEVER STOP INNOVATING ATTITUDE - DS18 stands out from other brands with our progressive designs and unwavering commitment to delivering the most technologically up-to-date products on the market.

PRO 6.5" Hybrid Mid-Range Loudspeaker with Built-in Driver 4-Ohm

DS18's Hybrid speakers give you the best of both worlds of mids and highs combined into one pro audio combination speaker. This high powered pro audio mega speaker combines both a 6.5 high volume midrange speaker that also has a high wattage driver attached to the rear to give you a full range of frequencies at an amazingly loud volume. These Hybrids have water resistant cones to help battle elements and are perfect for people looking to place a high wattage, high volume loudspeaker together without having to separately mount am additional driver.
SPECIFICATIONS
Nominal Diameter 6.5”
Nominal Impedance 4 OHMS
RMS Power Handling 225W
MAX Power Handling 450W
Sensitivity (1w/1m) 96dB
Frequency Response 100Hz-20KHz
Recommended Hi Pass Crossover 120 Hz
Number of Ways 2
Pair or Single Single

MID-RANGE SPECIFICATIONS
Voice Coil Diameter 1.5” / 38.6 mm
Voice Coil Former Material Glass Fiber
Winding Material CCAW
Cone Material Water Resistant Paper
Surround Material Cloth
Basket Material Aluminum
Basket Color/Finish Glossy Red
Magnet Material Ferrite
Magnet Weight 27 oz
Displacement volumen 0.047L

THIELE & SMALL PARAMETERS
Equivalent Volume Vas 2.211L
Excursion (one way) Xmax 9.2 mm
Free Air Resonance FS 199Hz
Mechanical Factor Qms 5.96
Electrical Factor Qes 1.524
Total Factor Qts 1.214
Mechanical Mass Mms 8.654g
Mechanical Compliance Cms 73.792 mm/N
BL Factor BL 4.769
Voice Coil Inductance Le 4.22mH
Cone Area Sd 145.26 Cm2
DC Resistance Re 3.2 ohms
Mechanical Mass w/o Air Mmd 6.7g&n

Item Specification

  • Item model number PRO-HY8.4B
    Style 8" Speaker
    Signal-to-Noise Ratio 97 dB
    Number of Items 1
    Power Source Corded Electric
    Control Method Voice
    Warranty Type Limited
    Compatible Devices Smartphone, MP3 Player, Laptop
    Woofer Diameter 8 Inches
    Includes MP3 player? No
    Controller Type Voice control
    Unit Count 1.0 Count
    Speaker Size 8 Inches
    Number of Power Levels 1
    Vehicle Service Type Car, Truck, Motorcycle, Boat
    Model Name PRO-ZTHY
    Impedance 4 Ohm
    Recommended Uses For Product Car Audio Pro Audio
    Included Components LoudSpeaker
    Subwoofer Diameter 8 Inches
    Subwoofer Connectivity Technology Wired
    Speaker Maximum Output Power 500 Watts
    Water Resistance Level Water Resistant
    Connectivity Protocol Coaxial
    Item Weight 5.85 pounds
    Connectivity Technology Coaxial
    Audio Driver Type Dynamic Driver
    Special Feature Midrange with Driver Horn
    Series Number 810005188333
    Mounting Type Car Mount
    Color Red
    Surround Sound Channel Configuration 1.0
    Frequency Response 20 KHz
    Speaker Type Surround Sound
    Is Waterproof TRUE
    Audio Output Mode Surround
    Audio Driver Size 8 Inches
    Product Dimensions 8.78"D x 5.43"W x 8.7"H
  • Product Dimensions: 5.43 "h x 8.78 "h x 8.7 "h. Weight: 5.85 lb
