The controller also offers the ability to control iris, focus, white balance, exposure, and on-the-fly speed control to control the finer camera settings on the PTZ cameras. An HDMI output allows you to send the camera video to a remote streaming unit, and the status information can also be included in the output. Other features include glowing buttons for working in the dark, 255 camera presets, nine quick presets, and four super preset buttons. You can import and export configurations using IP or via the USB port.
The SuperJoy supports a variety of camera models and manufacturers, and you can simultaneously control multiple brands such as HuddleCamHD, Sony, PTZOptics, BirdDog, and NewTek. The unit comes with an 8' long RS-232C cable and 12 VDC power supply, or it can be powered using Power-over-Ethernet (PoE).
Features
- Limited NDI|HX and Sony control
- IP, RS-232, RS-422, and RS-485 communication
- VISCA-over-IP, Pelco-P, Pelco-D, ONVIF, and VISCA protocols
- Camera on-screen display control
- Control four groups with up to seven cameras in each group for a total of 28 cameras
- Control multiple different PTZ camera brands simultaneously, including HuddleCamHD, PTZOptics, Sony, BirdDog, and NewTek
- Full pan/tilt/zoom PTZ camera control with speed adjustments on the fly
- 255 presets, nine quick presets, four super presets
- Exposure and white balance control
- Four customizable buttons using TCP, UDP, and HTTP control
- Program and RTSP output via HDMI
- Power-over-Ethernet (PoE) support
- Fine-tune zoom and focus control dials, redesigned joystick, and focus lock/unlock
- Glowing buttons for viewing in dark rooms
- Large LCD screen with controller status
- Import and export settings via LAN or USB
- Power adapter and 8' RS-232C cable are included
Compatibility
- VISCA: Serial connections include PTZ cameras with RS-232 and RS-485 from brands such as Aver, AIDA, Bird-Dog, Bolin, ClearOne, DataVideo, JVC, Lumens, Marshall Electronics, RGBLink, Sony
- Sony VISCA over IP: Includes PTZ cameras from AIDA, AVer, Bird-Dog, Bolin, BZBGear, ClearOne, JVC, Lumens, Sony
- PTZOptics VISCA: All PTZOptics cameras
- NDI (SuperJoy only): Includes NDI PTZ cameras from AIDA, AVer, BirdDog, Bolin, BZBGear, Canon, ClearOne, DataVideo, HuddleCamHD, JVC, Lumens, Marshall Electronics, NewTek, Panasonic, RGBLink
- Pelco-P and Pelco-D: Includes PTZ cameras from Bird-Dog, DataVideo, JVC, Lumens, RGBLink, Marshall Electronics
- Panasonic (PT-JOY-G4 and SuperJoy only): Panasonic cameras
- ONVIF: The PTZOptics IP joysticks can control ONVIF cameras (ONVIF stands for Open Network Video Interface Forum, originally created by Axis and the main pan, tilt, and zoom control protocol used by security cameras)
Box Contains
-
PTZOptics SuperJoy NDI|HX/IP & Serial PTZ Camera Joystick Controller
- 1 x 12 VDC Power Adapter
- 1 x RS-232C Cable (8')
-
PTZOptics SuperJoy NDI|HX/IP & Serial PTZ Camera Joystick Controller
- 1 x 12 VDC Power Adapter
- 1 x RS-232C Cable (8')
| Brand | PTZ Optics |
| Model | PTZOptics PT-SUPERJOY-G1 |
| MPN | PT-SUPERJOY-G1 |
| Type | Camera Joystick Controller |
| Number of Supported Cameras | 4 Channels via IP (7 Per Group) 4 Channels via Serial (7 Per Group) |
| Control I/O | 1x RJ45 (LAN) 1x Block (RS-422, RS-485) Output 1x DE-15/DB-15 (Pelco-D, Pelco-P, RS-232, VISCA) Outp |
| Video I/O | 1x HDMI (Loop Output) |
| Controls | 1x Pan/Tilt, Zoom Joystick |
| PoE Support | PoE 802.3af |
| Power Consumption | 6 W |
| Security Lock Support | No |
| Supported Control Protocols | IP Pelco-D Pelco-P RS-232 RS-422 RS-485 VISCA |
| Other I/O | 1x USB-A Input |
| Presets | 255 via IP, RS-232, VISCA |
| Touchscreen | No |
| Power Connectors | 1x Barrel / Coaxial |
| Input Power | 12 VDC |
| Operating Conditions | 14 to 122°F / -10 to 50°C at 10 to 90% Humidity |
| Dimensions | 14.6 x 7.1 x 4 / 37 x 18 x 10.1 cm |
| Weight | 3.7 lb / 1.7 kg |
