Features:
*4 Pole 12 Slot Hi-torque Motor Design
*CNC Machined 6061 T6 Billet Aluminum Heatsink Can
*High Purity Copper Windings Maximizes Efficiency
*High RPM ABEC5 Oversized Bearings
*Universal fit,fits all 1/10 brushless cars-multi-mounting system for M3 screws
*Precision balanced rotor,smoothness for best reliability and maximum RPM
*Stator - Super Thin (0.2mm) Laminations
*Removable/Replaceable Rotor
*Precision Engineered for Maximum Energy Conversion
Specification:
Brand: KingVal
Product: Brushless 550
Motor Size: ø36x55mm
Watts: 1200
Rotor Poles: 4
Max RPM: 50000
Shaft Diameter: 3.175mm
Length of extend shaft: 17mm
Connector: 4.0mm gold
N.W: 220g
KV(RPM/Volt): 4300
Max voltage: <12V
Max Amps: 100A
IO: 3.7A
Resistance: 0.0058
KV(RPM/Volt): 3800
Max voltage: <13V
Max Amps: 92A
IO: 2.8A
Resistance: 0.0083
KV(RPM/Volt): 3500
Max voltage: <14V
Max Amps: 85A
IO: 2.5A
Resistance: 0.0089
KV(RPM/Volt): 3300
Max voltage: <15V
Max Amps: 80A
IO: 2.3A
Resistance: 0.0095
KV(RPM/Volt): 2600
Max voltage: <19V
Max Amps: 63A
IO: 1.5A
Resistance: 0.0146
KV(RPM/Volt): 2350
Max voltage: <21V
Max Amps: 57A
IO: 1.3A
Resistance: 0.0152
KV(RPM/Volt): 1950
Max voltage: <26V
Max Amps: 46A
IO: 1.2A
Resistance: 0.0231
KV(RPM/Volt): 1750
Max voltage: <28V
Max Amps: 43A
IO: 1.0A
Resistance: 0.0258
KV(RPM/Volt): 1400
Max voltage: <36V
Max Amps: 33A
IO: 0.7A
Resistance: 0.0378
Package List:
1 x 550 Brushless Motor
1 x Manual
| Item Specifics | |
|---|---|
| Brand : | KingVal |
| Item : | 550 Brushless Motor |
| MPN : | Does Not Apply |
| EAN : | Does Not Apply |
| Country/Region of Manufacture : | China |
| Material : | Metal |
| KV Value : | 4300/3800/3500/3300/2600/2350/1950/1750/1400KV |
| Model : | 550 |
| Motor size : | ?36x55mm |
| Rotor poles : | 4 |
| Shaft Diameter : | 3.175mm |
| Compatible Scale : | 1:10 |
