E70-915T14S2 14dBm 915M CC1310 915MHz SOC Wireless Transmitter and Receiver
| RF Parameter | Value | Remark |
| Working frequency | 907~922.5 MHz | Default: 915MHz (24MHz oscillator) |
| Transmitting power | 4~14 dBm | Default: 14dBm（About 25mW） |
| Receiving sensitivity | -108 dBm | Air data rate: 50kbps |
| Air data rate | 2.5k~168kbps | Default: 2.5kbps |
| Test distance | 1500m | In open and clear air, with maximum power, 5dBi antenna gain, height of 2m, air data rate: 2.5kbps |
| Hardware Parameter | Value | Remark |
| IC |
CC1310F128RSM |
|
| FLASH |
128 KB |
|
| RAM |
20 KB |
|
| Core |
Cortex-M3（MCU）+Cortex-M0（RF） |
|
| Size |
14 * 20 mm |
Without SMA |
| Antenna type |
IPEX / Stamp hole |
|
| Communication interface |
UART |
Baud rate: 1200~115200, default: 9600 |
| Package |
SMD |
|
| Buffer |
2048 bytes buffer |
Defined by user |
| Electronic parameter | Min. | Typ. | Max. | Unit | Condition |
| Power supply | 2.1 | 3.3 | 3.8 | V | |
| Communication level | 2.1 | 3.3 | 3.8 | V | |
| Transmitting current | 33 | 36 | 40 | mA | 14dBm（25mW） |
| Receiving current | 6 | 8 | 9 | mA | |
| Sleep current | 1.0 | 1.2 | 2.7 | μA | |
| Operating temperature | -40 | 20 | +85 | ℃ | |
| Operating humidity | 10 | 60 | 90 | % | |
| Storage temperature | -40 | 20 | +125 | ℃ |
