The Arturia PolyBrute is a powerful 6-voice polyphonic analog synthesizer with powerful morphing capabilities and multi-axis performance controls for next-generation musical expression. The PolyBrute is designed for music producers, sound designers, performing musicians, or anyone looking to explore sound in perpetual motion. The morph function allows a sound to exist in two states (A and B) within a single preset, with seamless morphing between them. In fact, you can copy any A or B component of a preset to what you are currently editing, making for fast and easy sonic transformations. Coupled with the Morphee three-dimensional performance touchpad, and you've got intricate morphing expression right at your fingertips. Manipulate any facet of PolyBrute's sound, from delicate morphing to extreme dynamic shifts, across the X, Y, and Z axis in an instant.The PolyBrute's architecture starts with two Brute waveshaping oscillators capable of a wide pallet of timbral versatility. Both oscillators generate three basic waveforms (sawtooth, triangle, and square with pulse-width control), which can be mixed creating unusual and harmonically rich tones. Anything can be created from airy pads to snarling bass riffs. VCO2 also includes a sine wave sub-oscillator that runs an octave below the fundamental pitch. There are various FM capabilities as well as hard- and soft-sync options creating even more dynamically diverse tones. Additionally, a noise generator can be added to the mix and features a knob for dialing any color from red noise with its darker rumble to white noise with its crisp, multispectral character.

The filter section sports a continuously variable 12 dB Steiner Parker filter with low-pass, high-pass, and bandpass, and a classic 24 dB low-pass ladder filter with gain compensation, which prevents the reduction of lower frequencies that accompany higher resonance levels. Filter 1 includes the famous Arturia Brute Factor feedback filter for warming up the low end and producing monster growls, while the distortion circuit of Filter 2 controls the ladder filter's feed into the VCA.There are three envelope generators including dedicated ADSRs with velocity for the VCF and VCA. The third envelope is freely assignable to any parameter in the matrix and includes a delay before the ADSR section. Additionally, there are three LFOs for adding modulation to any parameter. LFO 1 and 2 offer sine, triangle, square, down-sawtooth, up-sawtooth, sample-and hold, and slewed random waveforms. LFO 1 features a Phase control, which adjusts where the LFO wave cycle starts, while LFO 2 features Fade In, which offsets the start of LFO2 and fades it in gradually. LFO 3 offers a sweepable LFO waveshape from logarithmic to linear and finally exponential. If that weren't enough, each LFO can have its own sync division setting, allowing for independent binary, triplet, or dotted options.

• 100% analog signal path provides the rich interactive sound that synth enthusiasts crave
• Built around a 61-note full-sized keyboard with aftertouch and mod and pitch wheels
• Dual VCOs with UltraSaw and Metalizer deliver sought-after Brute-series sound
• Shape your sound with Steiner-Parker and ladder filters for an added range of character
• Simple navigation (no menus or shift commands) makes operation simple and intuitive
• Instantly route signals, recall presets, and more via the matrix button array
• Expressive controls including the cutting-edge Morphée pad and a wooden ribbon controller
• 64-step sequencer lets you add motion to your sounds and create complex phrases
• Enhance your sounds with amazing onboard digital effects including delay, reverb, and more
• Included editor/librarian software and 768 preset slots with 384 factory presets make finding the perfect patches easy
• Easy-to-read OLED display for preset browsing
• Integrates easily into your setup with MIDI and USB interfacing
• Robustly constructed with beautiful black walnut cheeks and high-quality knobs and faders

Box Contains

Arturia PolyBrute Analog Morphing Matrix Synthesizer

• Power Cord
• Limited 1-Year Warranty

Box Contains

Arturia PolyBrute Analog Morphing Matrix Synthesizer

• Power Cord
• Limited 1-Year Warranty

Brand	Arturia
MPN	551001
Type	Synthesizer
Keyboard	61-Note (5-Octave), Velocity Sensitive, Channel Aftertouch, Adjustable Curves
Polyphony	6 Voices
Synthesis Method	Analog Morphing Synthesizer Mono, Unison, Poly Voicing Single, Split, Layer Modes
Presets	768 Arranged in 8 Banks of 96 (with Nearly 400 Factory Presets)
Digital Effects	Modulation Chorus Phaser Alternate Flanger Phaser 12p RingMod BitCrusher Soft Floanger Phase Flanger DownSampler Delay BBD (Bucket-Brigade Device) Ping Pong Alternate: Stereo Delay Long Delay BBD PingPong Karplus Stereo Spread Parallel BBD Spread Reverb Hall Plate Alternate: Bright Plate Room Dreamy Spring Delayed Plate
Sequencer / Arpeggiator	Polyphonic Up to 6 Notes Record and Play Back Up to 3 Modulation Tracks Sequences Can Hold Up to 64 Steps; Arpeggios Can Have Up to 32 Steps Swing, Time Division Settings Multiple Playback Modes and Directions Convert Arpeggios to Sequences Step Record/Editing Matrix Arpeggiator Mode: for constructing complex arpeggios Tempo Range: 30 to 240 BPM
Performance Control	Morphée: 3-D Controller that Modulates Parameters Along the X, Y, and Z Axes Simultaneously Aftertouch (Pressure Sensitivity) Ribbon Controller Pitch and Modulation Wheels Octave Buttons can Shift Keyboard Range ±2 Octaves from Center
Inputs and Outputs	Expression Pedal Input: 2 x 1/4" / 6.35 mm TRS (Tip = Pot Center Tap; Ring = 3.3 V; Sleeve = Ground) Sustain Pedal Input: 1/4" / 6.35 mm (Normally Open, Includes Polarity Switch) Sync I/O: 2 x 1/8" / 3.5 mm TRS (Gate: 0-5 V) Master Output: 2 x 1/4" / 6.35 mm TS (+4 dB Level)
MIDI	In, Out, Thru
USB	USB Type-B
Headphone Output	1/4" / 6.35 mm (Front Panel)
Temperature Range	59 to 95°F / 15 to 35°C
