Features

-Manufactured from high quality cast iron for durable usage and sound dampening-Dimensional accuracy, durability, application specific design and corrosion resistant features-Tubes sized and shaped to match cylinder-head exhaust port-Special surface treatment to resist corrosion for an increase in power and -Fully tests under extreme conditions to withstand high temperature and long-life use-Quality fully guaranteed and professional installation recommended.

Turbo flange: T3
Mount type: top mount / high mount
External Wastegate: 38mm. You can plate it off if intending to use internally wastegated Turbo (The blocking plate is included as shown in the picture)

Turbo Details
Flange: T3
Cooled Type: Oil cooled
Bearing: Journal bearing
Turbine port:  V band
Waste gate actuator     : Adjustable from 7.5psi - 14.53 psi
Housr Power: 300-400 HP
Compressor Wheel: A / R: 0.5 ||Ind:50.5 mm|| Exd:76 mm|| Trim: 44.2
Turbiner Wheel: A / R:0.63 ||Ind:65.5 mm|| Exd:55.9 mm|| Trim: 72.8

Oil Feed Oil Return Lines Details
Oil return line length: 550mm
Oil return line inner diameter: ¢21
Oil feed line length: 1000mm
Oil feed line inner diameter: ¢14

Other Details
Warranty    : 2 year for any manufacturing defect

Notice
- Many dealers and customers have bought this kit. According to their feedbacks, they match well. However, modification may be required.
- This oil line kit is an aftermarket kit. Not all the component parts will be direclt bolt on your car. You may still need some accessaries of your OEM oil line kit.
- No instruction will be included; professional installation and alignment is suggested.
- Please feel free to contact us for whatever we can help via eBay message.
