BT-650 Tysso Wireless Extra Long Range 50M Barcode Scanner with USB Recharge Cradle NEW!!

Product Description

The BT-650 series handheld barcode scanner is designate for long distance data scan applications. Incorporating Bluetooth wireless technology, BT-650 scanner offers the users up to 50 meters of transmission range from the receiver (recharge/communication cradle). The BT-650 is capable of storing thousands of data even when the scanner is our of the range from the cradle. With the highly sensitive scan module, BT-650 can capture barcodes easily even the barcodes are in poor condition. This feature ensures BT-650 capable of fast-capture and process demands. By adapting exceptional power saving design, the BT-650 wireless barcode scanner can operate much longer than ordinary scanners and ensure the high grade reliability. Furthermore, the user-friendly operation and large memory capacity characteristics enable BT-650 to be a cost-effective yet reliable data-scan solution.

Features

Light-weight and easy to operate
Scan Speed: 100 scans/sec
Integrated recharge/communication cradle with Bluetooth class 1 receiver
Transmission Range: up to 50 meters (open space)
High barcode readability, 0.1 mm resolution
Multiple operating modes selectable (On-line/Batch/Recapture)
Various barcode standards support
Large memory capacity ( 15,000 )
USB HID Interface

Specification

General

Scan Rate: 100 scans/sec
Sensor Type: CCD
Wavelength: 660nm ± 10nm
Maximum Pitch Angle: ±65 degrees
Minimum Skew Angle: ±50 degrees
Minimum Barcode Width: 0.1 mm (4 mil)
Depth of Field: 3~46 cm
Contrast Ratio: 45%
Scan Patten: Single scan line
Resolution: 0.1mm (4 mil)
System Interface: USB Keyboard Wedge
Indicator: Buzzer and LED illumination
Buffer Capacity: 192KB or approx. 15,000 scans (EAN 13 )
RF Frequency Band: 2.4~2.4835GHZ, unlicensed ISM band
Transmission Range*: Max. 50m, possibly over 70m in open spaces
Readable Bar Code: Symbologies, RSS Codes, EAN, UPC, I 2 of 5, Codabar, Code 39, Code 128, China Postage, Code 93, Code 11, MSI-Plessy, Code 4
Configuration Utility: Windows-base, 2000/XP/Vista/Windows 7

Electrical

Power Input: 5VDC ±5% (Scanner) / 5VDC ±5% (Cradle)
Power Consumption (Operation Mode):

85 mA (Bluetooth On)

75 mA (Bluetooth Off)
Power Consumption (Sleep Mode):

10 mA (Bluetooth On)

0.7 mA (Bluetooth Off)

Battery

Battery Type: Rechargeable Lithium-ion Battery
Battery Capacity: 2200mAh
Recharge Time: 6-8 Hours (approx.)
Recharge Connection: Battery charge with Recharge/Communication Cradle

Others

Operating Time: > 8 Hour (approx.) (approx. 40,000 scans/per charge)
Material: ABS
Color (Upper Cap/Handgrip): Black/Black
Compliance: FCC class A
Weight: Scanner: 170g ; Cradle: 190g
Dimensions: 167.5 x 72 x 78 mm (Scanner Unit) ; 90.5 x 70 x 60 mm (Cradle)
Ambient Light: 4500 lux
Operating Temperature: 0°C~40°C
Operating Humidity: 20% - 80% RH, non-condensing
Storage Temperature: -20°C~ 65°C
Storage Humidity: 5% - 95% RH, non-condensing

Photos

Click image to enlarge.
