Product Description
| Category | Item | Specification |
|---|---|---|
| Basic Information | Full Model | ZK4704-0421-2050 |
| Product Type | EtherCAT P pre-assembled M8 4-pin P-coded hybrid cable (signal + 24V power integrated) | |
| Cable Length | 2.05 m | |
| Cable Structure | Shielded round industrial PUR cable, 4-core integrated power & differential Ethernet signal | |
| Net Weight | Approx. 160 g | |
| Protection Class | Cable outer sheath IP67 compatible with matching M8 connectors | |
| Connector Configuration | End A | M8 4-pin P-coded male straight plug |
| End B | M8 4-pin P-coded female straight socket | |
| Pin Assignment Standard | EtherCAT P standard pinout: 1 Tx+/GNDs, 2 Rx+/GNDp, 3 Rx-/Up, 4 Tx-/Us | |
| Electrical Transmission Spec | Communication Standard | 100BASE-TX EtherCAT 100 Mbit/s full duplex |
| Power Carrying Capacity | Us (system) / Up (actuator) each support max 3 A DC 24V | |
| Characteristic Impedance | 100 Ω ±15 Ω differential Ethernet pair | |
| Voltage Rating | 60 V DC SELV industrial control voltage | |
| Insulation Resistance | ≥ 100 MΩ at 500 V DC | |
| Cable Mechanical & Material Spec | Outer Sheath Material | PUR polyurethane oil-resistant, abrasion-resistant, halogen-free |
| Cable Outer Diameter | 5.5 mm | |
| Min Bending Radius Fixed Installation | 8 × cable outer diameter | |
| Min Bending Radius Dynamic Drag Chain | 12 × cable outer diameter | |
| Tensile Load | Max 100 N short-term tensile force | |
| Chemical & Environmental Resistance | Resist Properties | Oil, coolant, weak acid, alkaline, UV resistant for indoor workshop |
| Not Suitable For | Direct outdoor sunlight long-term exposure, strong solvent immersion | |
| Environmental Conditions | Operating Temperature Fixed Install | -40 ℃ ~ +80 ℃ |
| Operating Temperature Drag Chain | -25 ℃ ~ +70 ℃ | |
| Storage Temperature | -45 ℃ ~ +85 ℃ | |
| Relative Humidity | 5% ~ 95 %, non-condensing | |
| Vibration Compliance | EN 60068-2-6 industrial vibration standard | |
| EMC & Safety Certifications | EMC Performance | Full copper braided shielding, suppresses EMI/RFI interference |
| Approvals | CE, UL AWM industrial cable certification, RoHS compliant | |
| Variant Code Breakdown | ZK4704 | Series: EtherCAT P M8 P-coded hybrid cable series |
| -0421 | Connector variant: male straight / female straight pair | |
| -2050 | Length code: 2.05 meters finished cable | |
| Core Feature Summary | Key Advantages | Single hybrid cable transmits EtherCAT communication + dual 24V power simultaneously; factory pre-terminated plug eliminates on-site wiring error; PUR flexible drag-chain capable cable; full shielding anti-interference for machine-side EPP modules; standard P-coded M8 compatible with all EK13xx, EPP series EtherCAT P devices |
| Typical Application Scenarios | Usage | Connect EK1322 EtherCAT P junction terminal to EPP IP67 field I/O boxes; machine tool, packaging, conveyor decentralized EtherCAT P field wiring; robot peripheral sensor/actuator hybrid cable connection; cabinet-free distributed automation single-cable wiring layout |
