Product Description
| Category | Item | Specification |
|---|---|---|
| Basic Information | Full Model | EPP2338-1001 |
| Product Type | EtherCAT P Box, 8-channel multifunctional digital combi I/O (each channel freely IN/OUT), IP67 field module | |
| Housing Material | PA6 industrial polyamide plastic | |
| Dimension (W × H × D) | 30 mm × 126 mm × 26.5 mm | |
| Net Weight | Approx. 165 g | |
| Protection Class | IP65 / IP66 / IP67, direct machine field mounting without cabinet | |
| Bus Interface (EtherCAT P Single Cable) | Bus Ports | 2 × M8 4-pin A-coded shielded sockets (IN / OUT daisy chain, signal+24V power over one cable) |
| Pin Definition | 1:Tx+/GNDs; 2:Rx+/GNDp; 3:Rx-/Up; 4:Tx-/Us | |
| I/O Sensor Connectors | Channel Ports | 8 × M8 3-pin A-coded female sockets for sensors/actuators |
| I/O Pinout | 1:+24V Up; 3:GNDp; 4:Universal IN/OUT signal pin | |
| Digital Input Spec | Channel Feature | Each channel built-in input circuit, auto feedback of output state to input process image, no software mode switch needed |
| Nominal Voltage | 24 V DC (-15% ~ +20%) | |
| Logic 0 / 1 Threshold | -3…+5 V / 11…30 V DC, compliant EN 61131-2 Type1/3 | |
| Input Filter (1001 variant) | Fixed 3 ms anti-bounce filter for mechanical switches | |
| Per-channel Input Current | 3 mA typical | |
| Digital Output Spec | Max Current Per Channel | 0.5 A PNP sourcing, independent short-circuit protection |
| Total Output Current Limit | Max 4 A for all 8 channels combined | |
| Short-circuit Trip Current | Typ. 1.5 A per channel | |
| Switching Time | TON ≈ 50 µs, TOFF ≈ 100 µs | |
| Supported Loads | Resistive lamps, small solenoid valves, inductive actuators | |
| Built-in Protection | Reverse polarity, over-temperature, per-channel short-circuit lockout | |
| Sensor Power Supply | Internal 24V Sensor Feed | Total max 0.5 A, full short-circuit protected for all connected sensors |
| Galvanic Isolation | Dielectric Withstand Voltage | 500 V AC isolation between EtherCAT P bus logic and field I/O circuit |
| Power Consumption | Us Module Supply Draw | Typ. 100 mA (module base consumption, exclude I/O load) |
| Up Auxiliary Circuit Draw | Typ. 20 mA (exclude sensor & actuator loads) | |
| EtherCAT Bus Functions | Distributed Clocks | Not supported |
| Process Image Data | 8 input bits + 8 output bits | |
| Address Assignment | Auto-detected by EtherCAT master, no DIP switches | |
| LED Diagnostic Indicators | System LEDs | RUN (bus communication), ERR (fault alarm), Us power, Up auxiliary power |
| Channel LEDs | 8 independent yellow LEDs, lit when signal channel logic high | |
| Mechanical Mounting | Fixing Holes | 2 × Ø3.5 mm holes for M3 screws, multi-angle installation |
| Environmental Conditions | Operating Temperature | -25 ℃ ~ +60 ℃ full continuous load |
| Storage Temperature | -40 ℃ ~ +85 ℃ | |
| Relative Humidity | ≤ 95 %, non-condensing | |
| Vibration & Shock Standard | EN 60068-2-6, EN 60068-2-27 industrial standard | |
| EMC & Safety Certifications | EMC Compliance | EN 61000-6-2 (industrial immunity), EN 61000-6-4 (industrial emission) |
| Approvals | CE, UL Listed | |
| Variant Distinction Note | EPP vs EP Series | EPP = EtherCAT P single hybrid cable (signal+power); EP = separate bus + power M8 dual cables |
| Suffix -1001 vs -0001 | -1001: 3ms input filter for mechanical switches; -0001: 10µs fast filter for high-speed sensors | |
| Core Feature Summary | Key Advantages | Single EtherCAT P cable wiring reduces field wiring workload; IP67 waterproof dustproof machine-side installation; 8 universal IN/OUT combo channels flexible allocation; per-channel short-circuit protection; built-in shared short-proof sensor power |
| Typical Application Scenarios | Usage | Cabinet-free distributed machine I/O, robot peripheral sensors & small valve control, packaging line field side signal collection, conveyor proximity/photoelectric mixed input-output stations, mobile machinery decentralized EtherCAT P automation |
