Product Description
| Category | Item | Specification |
|---|---|---|
| Basic Information | Full Model | EL2202 |
| Product Type | EtherCAT Terminal, 2-channel relay output, potential-free SPST NO contacts | |
| Mounting Rail | Standard 35 mm DIN rail (EN 60715) | |
| Dimension (W × H × D) | 12 mm × 100 mm × 68 mm | |
| Net Weight | Approx. 65 g | |
| Protection Class | IP20, cabinet installation only | |
| Relay Contact Parameters | Channel Quantity | 2 independent normally open potential-free relay contacts |
| Max Switching Voltage | 250 V AC / 30 V DC | |
| Rated Resistive Current | 2 A per channel | |
| Max Switching Capacity | 500 VA (AC) / 60 W (DC) per channel | |
| Mechanical Service Life | ≥ 10,000,000 cycles without load | |
| Electrical Service Life | ≥ 100,000 cycles under full rated resistive load | |
| Switching Time | Typ. 10 ms pick-up, 5 ms drop-off | |
| Coil Protection | Built-in freewheeling diode to suppress coil surge voltage | |
| Load Circuit Note | No on-board channel short-circuit protection; external fuse required for load side | |
| Galvanic Isolation | Dielectric Withstand Voltage | 2500 V AC isolation between E-bus logic and field contact circuit |
| Power Consumption | Typical E-bus Current Draw | 80 mA (all relays off); additional 25 mA per energized relay |
| EtherCAT Bus Functions | Distributed Clocks | Not supported |
| Process Image Data | 2 relay control output bits + channel diagnostic status flags | |
| Address Configuration | Automatic EtherCAT detection, no DIP switches | |
| Wiring Terminals | Terminal Type | Spring screw terminals |
| Applicable Wire Size | Solid wire: 0.08–1.5 mm²; ferrule stranded wire: 0.14–0.75 mm² | |
| LED Status Indicators | System LED | RUN LED for EtherCAT communication status |
| Channel LEDs | Separate yellow LED for each channel, illuminated when relay actuated | |
| Environmental Conditions | Operating Temperature | -25 ℃ ~ +60 ℃ full continuous load |
| Storage Temperature | -40 ℃ ~ +85 ℃ | |
| Relative Humidity | ≤ 95 %, non-condensing | |
| Vibration & Shock Standard | EN 60068-2-6, EN 60068-2-27 | |
| EMC & Certifications | EMC Compliance | EN 61000-6-2 (industrial immunity), EN 61000-6-4 (industrial emission) |
| Approvals | CE, UL Listed, CCC | |
| Variant Comparison | EL2202 vs EL2262 | EL2202: 2A contact rating; EL2262: 3A higher load capacity |
| Core Feature Summary | Key Advantages | Slim 12 mm width; high 2500 V isolation; floating contacts compatible with AC/DC mixed loads; compact layout for low-power switching signals |
| Typical Applications | Usage Scenarios | Small AC contactors, indicator lamps, auxiliary safety switches, low-power heating elements, external valve control in machine tools and packaging lines |
