Element RC 40129 Enduro Comp fox Competition Rock Crawler Kit

Article number: AE40129

Element RC 40129 Enduro Comp fox Competition Rock Crawler Kit

This kit for the RC Crawler competition is packed with functions that you will bring through every gate. The light flat-cream chassis made of carbon fiber, which is held by aluminum struts, is stable, but light enough to keep the focus low. With a variety of shock absorbers and suspension positions, there are an infinite number of ways to coordinate the chassis.

Progress. You asked you should get. Here at element RC we strive to offer you the products you want. This time we have grown beyond ourselves and have developed a complete RC Crawler Competition Kit, the Enduro Comp fox.

This kit has been developed for the serious RC Crawler and is packed with features that will bring you through every gate. The light flat-cream chassis made of carbon fiber, which is held by aluminum struts, is stable and yet light enough to keep the focus low. With a variety of damper and suspension positions, there are an infinite number of ways to coordinate the chassis.

Like any good comprig, the Comp Fox is equipped with a DELRIN® skidplate that was angry 8 ° to master difficult breakovers and avoid a high center of gravity.

The heart of the compFox is our tried and tested stealth X (R) gearbox with overdrive and a forward aluminum engine bracket. This shifts the weight of the engine to the front axle and an ideal weight distribution of 60/40 is achieved.

In order to maximize the ground clearance, the Enduro Comp Fox is equipped with a newly developed set of portal axes with high ground clearance that have all-metal tooth wheels and ball bearings. With almost one inch more soil clearance compared to our straight standard axes is known that this RIG is serious.

But that's not all. We have also installed a few factory team shops, such as steel pivot balls, high-clearance links and aluminum threaded dampers to make the Enduro Comp fox a tough competitor on the rocks.

With all these features in a package, the new Enduro Comp Fox is the perfect equipment for all adventures that are waiting behind the next corner. Your journey starts here!

Chassis features

• Servo-on-Axle steering: The servo-on-axle steering ensures better performance and keeps the focus of the vehicle low.
• Carbon Fiber Flat Rail Chassis: The milled carbon fiber flat-rail chassis together with the aluminum chassis struts is light, stiff and stable and offers numerous options for the chassis tuning.
• Team brick dampers ex works: With almost one more customs more scope in the middle of the axis compared to the standard Straight axes, overcoming difficult obstacles is child's play.
• Steel joint balls: The steel joint balls are stable, reliable, abrasion-resistant and low-friction and enable a smooth impact even under extreme conditions.
• Delrin Angled Skid: The lower skid plate made from a solid, low-friction Delrin® block is angled by 7 degrees, while the gearbox remains flat to enable more ground freeness at the back and better transitions.
• PreWe-oriented engine bracket: The two-part aluminum motor holder relocates the engine to the front and bottom, in order to shift the weight of the front wheel and at the same time keep the focus as low as possible.
• Portal axis: When it comes to rock crawling, ground clearance is crucial. That is why the Enduro Comp fox competitive rockcrawler kit contains our brand new portal axles with high ground clearance. With almost one inch more ground clearance in the middle of the axis compared to conventional rigid axles, overcoming difficult obstacles is child's play. In order to master the enormous torque of the portal axes, we not only used metal tooth wheels throughout, but also six screws to attach the portal gear. So many screws ensure a more stable portal housing and reduce the risk that the gears will loosen under heavy load.

The scope of delivery includes our STEALTH® X transmission that offers the possibility to adapt the rear drive ratio. In the box you get the standard 5.7% and 11.83% gear options. Coupled with our new portal axes with zero percent undertraction, this is the perfect mild setup for the average crawler.

If even more reduction in the rear is desired, an optional 12/23 tooth wheel set (#42372) is available separately, which ensures an additional 36% over-control from axis to axis!

Additional features

• New portal axes with high freelance
• New carbon fiber "Flat-Rail" chassis
• New aluminum chassis struts and body containers
• New from Delrin® milled and flush, angled lower ski slab
• New 2-part engine plate made of aluminum
• Factory Team Aluminum Thread Dampers
• Factory Team Stahl-Pivot Balls
• Factory team 5 mm high performance steel
• Highly flexible handlebar
• Servo-on-axis steering
• Universal drive axes at the front and back
• Aluminum control plates
• Optimized ball pans for a more fluid axle frightening
• Telescopic drive shafts at the front and back
• Drive shaft toothing made of extruded aluminum
• Edited drive pinion
• Metal tooth wreath
• Edited steel wave above
• Including metal ball bearings
• 25t servo-servo-horn made of steel

Specifications
