Overview

Over the last 20 years, Bio-Tek has become the leader in microplate washing. This proven expertise in the design and manufacture of the highest quality microplate washers has evolved into the ELx405 ^TM Series of microplate washers. Precise, fast and easy to use -- the ELx405 Series includes four models, each with its own innovative features. The NEW ELx405 HT is designed specifically to rapidly wash 384-well microplates and includes Bio-Tek's patented Dual-Action manifold to ensure optimal performance and easy maintenance. The ELx405 Select is the market leader in 96-/384-well washing. The Select also has our patented Dual-Action ^TM manifold, providing independent control of both dispense and aspirate manifolds for precise overfill washing and overflow protection in both 96- and 384-well microplates. This unique design washes both 96- and 384-well plates without the need for any hardware changes. With its slanted dispense tubes, full control of dispense and aspiration rates and unique x, y, z positioning, the ELx405 Select is ideal for cell-based applications.

For those applications that use only 96-well microplates, the ELx405 Auto Plate Washer is an ideal choice for performance and value! The ELx405 Auto Washer is the most precise and reliable washer available. Many unique features lower background absorbance values and increase the signal-to-noise ratio of typical ELISA assays. The ELx405 Magna is specifically designed for those applications using magnetic bead technology. A second carrier positions the magnet plate close to the microplate bottom, securing magnetic beads during the critical aspiration cycles. All ELx405 Series washers come standard with Bio-Tek's unique AutoPrime ^TM and AutoRinse ^TM functions for reliable performance, and can be interfaced into standard robotic systems with Bio-Tek's easy-to-use ActiveX® component.

Hardware

• Patented Dual-Action ^TM manifold on the ELx405 Select and ELx405 HT provides independent control of the aspirate and dispense manifolds for precise overfill washing and overflow protection
• Internal positive displacement pump eliminates the use of troublesome pressure delivery systems and allows the use of any size dispense reservoir
• Built-in priming trough allows automatic manifold priming and rinsing during both operation and maintenance modes and eliminates the need for 'blank' plates when used in automated robotic systems
• Fully variable dispense volumes, flow, and aspiration rates provide 'total control' of the washing cycles from a gentle cell-washing application to vigorous wash for high-binding assays
• Built-in fluid flow, fluid detection, and vacuum sensing provide complete protection for unattended operation
• Optional external valve module connects four reagent bottles with automatic switching between reagents

Software

• 75 programs
• Link up to 10 programs (if valve module is attached, links multiple buffers automatically)
• Pre/AutoPrime
• 10 cycles/wash
• Crosswise aspiration well
• Fully programmable:
  • dispense height
  • aspiration height
  • aspiration delay
  • soak
  • shake
  • aspiration rate
  • horizontal aspirate and dispense position
• External programming/downloading available through RS-232 port

Specification

Microplate types	All standard flat-, round-, or V-bottom plates/strips in 96-well array 384- or 96-well plates (Select) 96-well plate (Magna) 384-well plate (HT)
Processing speed	<20 seconds (1 cycle, 400 µl/well, 384 wells) <30 seconds (3 cycles, 300 µl/well, 96 wells) <80 seconds (3 cycles, 100 µl/well, 384 wells)
Wash cycles	1-10
Volume range	50 to 3000 µl/well 25 to 3000 µl/well (HT)
Fluid delivery	Internal positive displacement pump
Buffer selection	Valve module option - up to 4 buffers
Dispense precision	<2% CV typical
Residual volume	<1.5 µl/well typical
Soak Time	1 to 600 seconds
Shaking	User-programmable speeds and timing
Manifold	96-channel aspiration/dispense (Auto/Magna) 96-channel patented Dual-Action, with separate dispense/aspiration (Select) 192-channel patented Dual-Action, with separate dispense/aspiration (HT)
Sterilization	Chemical
Supply bottle volume	3.7 liter
Onboard software	75 programs Program linking Overflow wash/overfill protection 5 maintenance programs
PC software	ActiveX component (optional)
Power	100 to 240 V AC , 50/60 Hz
Dimensions	17" D x 14" W x 9" H (43.2 x 35.6 x 22.9 cm)
Weight	28 lbs (12.5 kg)
Regulatory	CE Mark, ETL Mark for UL3101-1 CAN/CSA C22.2 No. 1010.1 Conforms to IEC 1010-1
Automation	Compatible with Bio-Stack and Fastrack microplate stacking devices.

Condition

Used. Unit is in excellent functional and cosmetic condition. Item received from a working environment.

Video of this instrument running self check and washing:

Includes

• (1) Bio-Tek Biotek ELX405R ELX405 Microplate Washer for 96 well standard microplate
• (1) Vacuum pump
• (4) Bottles and a reagent holder tray
• (1) power cord

BBR1

Warranty

30 Day warranty. We pledge to offer the best service and warranty to all of our customers! We are extending a 30 Day warranty on this item. This is our way of saying thank you for allowing us to serve you.

Certification

This is a genuine product from this manufacturer.

Disclaimer

The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. the item is subject to FDA regulation, we will verify your status as an authorized purchaser of this item before shipping of the item."

Regardless of the origin of the equipment, documentation provided or identification appearing upon the equipment, the equipment described and offered here is in no way certified for, recommended for, or offered for any specific use. The purchaser agrees that the seller shall not be held responsible or liable for any injuries or damages, whether incidental or consequential, associated in any way with the equipment. The purchaser, by bidding on this equipment, indicates their acknowledgment of, and agreement to the terms of this disclaimer. it is the purchaser's responsibility to have the item inspected and certified by a qualified professional before use!
