Lowrance Eagle 7 with 83/200 HDI Transducer, Pre-loaded Worldwide Basemap
PART NUMBER: 000-16308-001
Description
The Lowrance Eagle 7 with 83/200 HDI is a user-friendly fish finder designed to enhance the fishing experience with advanced sonar technologies and easy installation.
This 7-inch model benefits from the following features:
User-Friendly Design
Designed to make fishing simple and enjoyable, allowing users to focus on fishing rather than setup.
Autotuning Sonar
Automatically adjusts sonar settings for optimal performance, ensuring a quick and efficient setup.
Lowrance CHIRP Sonar
Provides high-resolution views of individual fish targets, improving target separation and clarity.
DownScan Imaging
Offers photo-like images of underwater structures directly beneath the boat, helping to identify fish-holding areas.
FishReveal Technology
Combines CHIRP sonar and DownScan Imaging for better fish identification and target separation.
IPS Screen
Higher resolution and improved visibility from all angles, even in bright sunlight and with polarised sunglasses (compared to older models).
Worldwide Base map Chart
Comes pre-loaded, providing essential navigation information.
Option to upgrade to CMAP DISCOVER
Offers detailed and accurate charts for inland and coastal areas, enhancing navigation and fishing efficiency.
Transducer
83/200 kHz HDI Transducer suitable for various depths and provides versatile imaging capabilities for different fishing environments.
Features
- 83/200 HDI MED/HIGH Transducer with Autotuning sonar
- Worldwide Base map
- IPS screen, viewable from all angles, even in polarised glasses
- Reliable twist-lock connector system for easy installation in any boat or kayak
- SD card slot for software updates, Genesis Live recording and charting add-ons
- See fish hiding in cover with FishReveal™ mode
- Increase contrast and viewability with all-new Imaging colour palettes
Specifications
| Display | |
| Backlight Color | Pure white LED |
| Display Resolution | 800 x 480 |
| Display Size | 7 inches |
| Screen Brightness | 1000 NITS |
| Viewing Angles | 80° top/bottom, 80° left/right |
| Connectivity | |
| SD Card Storage | 1 slot (microSD 32 GB maximum) |
| Sonar | 1 port |
| Charts supported | C-MAP DISCOVER. |
| Sonar | |
| Sonar compatibility | Integrated: CHIRP, Broadband, DownScan |
| Max depth: 200 kHz: 152m (500ft) DownScan: 91m (300ft) | |
| Max range: SideScan: 183m (600ft) side-to-side | |
| Sonar frequencies | CHIRP* 200kHz (High) 83kHz (Medium) 50 kHz (Low) *depending on transducer |
| DownScan 455 kHz (Low) 800 kHz (High) | |
| SideScan 455 kHz (Low) 800 kHz (High) | |
| Electrical | |
| Power Consumption max | 550 mA @ 12 V DC with backlight on full |
| Power Consumption min | 250 mA @ 12 V DC with backlight off |
| Power Consumption typical | 550 mA @ 12 V DC with backlight on full |
| Recommended Fuse Rating | 3A |
| Supply Voltage | 12v DC (10.8-17VDC) |
| 12v DC (10.8-17VDC) | |
| Environment | |
| Humidity | 60°C, 95% relative humidity (RH) for 48 hours |
| Operating Temperature Range | 5°F to 131°F (-15°C to 55°C ) |
| Storage Temperature Range | 4°F to 140°F (-20°C to 60°C ) |
| Waterproofrating | IPX7 with card door closed |
| GPS | |
| Correction | SBAS |
| Time to First Fix | 45s |
| MFD | |
| Cartography included | Worldwide basemap chart |
| Cartography supported | C-MAP DISCOVER, C-MAP Genesis Live |
| Waypoints, Routes, Tracks | 3000 Waypoints, 100 Routes, 100 Trails |
| Physical | |
| Compass Safe | 12" (300mm) |
| Dimensions W x H x D | 225.9 mm (8.89") x 139.8 mm (5.5") x 88.5 (3.48) |
| Mounting Type | Gimbal bracket or dash mount |
| Weight | 0.67 kg (1.48 lb) |
| Other | |
| Interface | Keypad:8-way directional keypad, Zoom +/- (MOB), Exit, Enter, Menu, Waypoint, Power / backlight |
| Warranty Period | 1 Year + 4 additional years of upgrade options totaling 5 years |
What's in the Package?
- Lowrance Eagle 7 with 83/200 HDI Transducer, Pre-loaded Worldwide Basemap
- Eagle 7
- 83/200 HDI Transducer
- Gimbal kit
- Power cable
- Documentation pack
