WF-9855-MBA 55 Amp RV Power Center Main Board Replacement for WFCO 9800 Series


WF-9855-MBA 55 Amp RV Power Center Main Board Assembly

Core Features

  • Enhanced Automatic Detection: Next-generation auto-detection technology for lithium (LiFePO4) and lead-acid (AGM/flooded/gel) batteries, with optimized charging profiles for faster, safer charging and extended battery cycle life.
  • Advanced Safety Mechanisms: Built-in overcurrent protection, reverse polarity protection, over-temperature shutdown, and surge protection; fully compliant with UL 458, RVIA, and NEC safety standards with visual and audible fault alerts.
  • Plug-and-Play Installation: Drop-in replacement for WF-9855 power center main boards, requiring only basic hand tools and 15 minutes or less for complete installation—no wiring modifications needed.
  • High-Efficiency Conversion: 85%+ power conversion efficiency reduces energy waste and heat generation, ideal for off-grid and boondocking RV applications.

Key Parameters

Parameter Name Detailed Specifications
Output Current 55 Amps continuous (12V DC)
Input Voltage/Frequency 90-130V AC, 50/60Hz (universal input)
Output Power 800 Watts continuous, 1000 Watts peak
Output Voltage Range Lithium: 14.2-14.6V DC; Lead-Acid: 13.6-14.4V DC (adjustable)
Efficiency ≥85%
Dimensions 7.125" (W) × 4.0" (H) × 2.25" (D)
Weight 4.8 lbs (2.18 kg)
Converter Type 4-stage smart charger (bulk/absorption/float/maintenance)
Warranty Period 1 Years limited warranty

Compatibility & Replacement

  • Direct replacement for WF-9855 RV power center main boards
  • Backward compatible with WF-8955 power centers (adapter included)
  • Compatible with all 9800 series WFCO power centers (9835, 9845, 9855)
  • Replaces obsolete Parallax 7155/7145 main board assemblies with no adapter required

Warranty Service

Warranty Information

1-year limited manufacturer's warranty

Coverage: Defects in materials and workmanship; includes technical support

Important Notes
  • Always disconnect AC power and disconnect battery terminals before installation to prevent electrical hazards.
  • For lithium battery systems over 200Ah, verify wire gauge (minimum 4 AWG) to maintain optimal charging performance.
  • Not compatible with 120V AC direct hardwiring—use only with WF-9800 series power centers.
