1296P/1080P Full HD Dash Cam

Car DVR Camera ( Driving Video Recorder )


Powered By deelife


● 2304 x 1296P Full HD resolution, Clearly recording.
● 170-degree Wide Angle Lens, Can cover over 4 lanes in front of the car.
● WDR technology & F/2.0 aperture, Enhance night vision video recording performance.
● 3-Axis G-sensor, Automatically locks the current video when a collision is detected.
● Seamless loop recording, automatically overwrites the earliest unlocked video.
● Parking monitor, Provide 24-hour monitoring under parking mode.
● Advanced H.264 photography compression technology keeps high-quality videos.
● Support up to 128GB TF card memory storage.
● Working temperature -20℃~70℃.


•  Or scan the QR code below

 General

 Brand

 deelife

 Model

 X4

 Color

 Black

 Material

 Zinc alloy + ABS

 Specifications

 Display

 4 Inch IPS LCD Screen, 16:9, 800 x 480 Resolution

 Lens

 F2.0 Aperture, 170deg Wide Angle Lens, 6-layer Glass

 G-Sensor

 Built-in High Precision 3-Axis Sensor

 Video Resolution

 2304*1296 ( 1296P ) ;1920*1080 ( 1080p ) ; 1280*720 ( 720P ) ;

 Wide Dynamic

 Enhanced e-HDR Dynamic State

 Video Encode

 H.264

 Video Format

 MOV

 Video Clip Size

 1296P (2304*1296), 30FPS, approximately 470M

 Audio

 Built-in High Quality Microphone & Speaker

 Expanded Storage

 MicroSD/TF Card, up to 128GB(MAX), FAT32/exFAT format

 Fixed Mode

Adhesive Holder/Sucker Holder (Easy to Remove, No Harm to Windshield & Heat Insulation Film)

 Power Supply

Cigarette Lighter Car Charger/ Fuse Box Power Cord, 5V/1.5A (supports 12V-24V), 3.5m length

 Battery

 300mAh 3.7V

 Power Consumption

 <3W

 Control Method

 Buttons

 Support Interface

 USB / TF card (maximum 128GB) / AUX-IN for Rear Camera

 Record Time
1296P Mode

 64GB micro SD card : About 7 hours 26 minutes, 149 videos

 32GB micro SD card : About 3 hours 40 minutes, 74 videos

 16GB micro SD card : About 1 hour 51 minutes, 37 videos

Package Including

1 x Car DVR

1 x Car Charger

1 x Fixed Bracket

2 x Cable Clip

1 x Cable Installation Tool

1 x English User Manual



32GB TF Card Specification (Optional)
● Type : MicroSDHC / MicroSDXC
● Speed Level : U1 or Class 10
● Reading Speed : Up to 80MB/s
● Waterproof Level : IPX7
● Continuous working time : >24 Hours
● File Format : Deelife X4 dash cam supports FAT32 / exFAT file system format.

--- Attention ---
● Please use high-speed TF card (Recommended Class-10/U1) and support 32GB/64GB/128GB (FAT32 exFAT Format)
● This device can ONLY work by connecting the car power with our original cables! Please do not run the device with your own power at home.
● If you use other chargers which cause the product to stop working, we do not assume any responsibility, please understand.

--- FAQ ---
● Q: Why the device can not turn on or flash after receiving it?
● A:
① Please connect to our original car charger/power cord, our X4 Dash Cam needs 5V/1.5A power supply. The computer's USB port usually be 5V/0.5A (Not enough).
② The built-in battery might be used up during transportation. Please charge it in the car for half an hour, and then click "reset" at the back of the device five times.
③ Check if there is a problem with the TF card, please take out the TF card, it may be that the file system format of the TF card is incorrect or the speed is lower than class 10.
④ Check if there is a problem with the rear-view camera, please unplug the rear-view camera.


● Q1: Why is the battery life so short?
● Q2: Why does my Car DVR always automatically power off in 10 seconds when I unplug the cable?
● A:
As the DVR's small size, the battery is designed for safety recording consideration
    ① Battery capacity is 300mAh.
    ② It is used to save the video when the power supply is cut off suddenly, it will not lose previously recorded video.
    ③ If turned on the parking monitoring function, it will automatically power on and shoot video when some collision happens.
    ④ For normal use, please connect our original car charger/power cord.



● Q: Do I need to manually turn on/off the dash cam?
● A:
After the dashcam is connected well to the car's cigarette lighter socket, no need to manually turn it on/off.
    ① Every time when the car is started (Such as, the cigarette lighter port is powered on), the dash cam boots up automatically.
    ② The dashcam will turn off automatically when the vehicle is turned off (Such as, the cigarette lighter port is powered off).


● Q: How to watch the recorded video?
● A:
    ① Please exit the video recording by pressing the "OK" button.
    ② Short press "MODE" button once, it will be the "Camera mode".
    ③ Short press "MODE" button again, it will be the "Video playing mode" to play the recorded video.

● Q: Why the "MENU/MODE" button is not working?
● A:
    ① Please check does it in the "video recording mode", if yes, please exit by pressing "OK" button.
    ② Then try to press the "MENU/MODE" button again.

● Q: Why does it only record many 3-minute videos, can it be 1 minute or 5 minutes?
● A:
    The default video recording length is 3 minutes each time.
    Because the car DVR will remove the earliest video automatically when the TF card is full.
    If the earliest video is too long, it will be removed at once. When you want to watch some videos earlier, they may have been deleted.
    You can change the time length in the setting, choose 1/3/5 minutes.


● Q: How to make the screen sleep or screen off when driving?
● A:
    ① Enter "Setting" by pressing "MENU" Button twice.
    ② Select the "LCD OFF" icon (LCD Brightness).
    ③ Set "OFF" to make the LCD never turn off. Set "30 seconds" / "1 minute" / "2 minutes" to make the LCD automatically turn off the when in video recording mode within "30 seconds" / "1 minute" / "2 minutes".


● Q: Why should I always delete videos manually?
● A:
    We recommend setting the "Gravity sensing" (G sensor) to "Low"/"Medium" level.
    When you set it to "High" level, our dash cam X4 will sense slight vibrations to lock the videos(marked as an accident), to prevent them from being covered by the new videos.
    If more and more videos are locked, it will occupy all the TF card memory.


● Q: Can I use the computer's USB port for the power supply?
● A: Can not.
    ① The computer's USB port usually be 5V/0.5A (Not enough).
    ② Our X4 dash camera needs 5V/1.5A. Please connect our X4 dash cam to our original car charger/power cord.
