OE/Part number:

4110446,4350260200, 4357004010, 4357004011, 4357060010,

538-58964,903-403, 4350260180, 43502-60180,4350260201,

43502-60201,4357060011,43570-60011

Compatibility:

For Dodge Ram 1500 2009-2010 V6 3.7L (Built After 12/08/2008)
For Dodge Ram 1500 2009-2010 V8 4.7L (Built After 12/08/2008)
For Dodge Ram 1500 2009-2010 V8 5.7L (Built After 12/08/2008)
For Ram 1500 2011 V6 3.7L
For Ram 1500 2011 V8 4.7L
For Ram 1500 2011 V8 5.7L

Specification:

Condition: New
Location: Front Wheel
Material: Bearing Steel
Position: Front Left and Right
ABS Sensor Cord Included: Yes
Anti Lock Braking System: Yes
Anti Lock Braking System Type: Sensor
Bolt Circle Diameter (IN): 5.5
Bolt Circle Diameter (MM): 139.7
Brake Pilot Diameter (IN): 3.09
Brake Pilot Diameter (MM): 78.4
Connector Quantity: 1
Driven Or Non-Driven Type Hub Assembly: Driven
Drive Type: Fits 4WD or 2WD Models
Flange Bolt Hole Quantity: 3
Mounting Type: Bolt-on
Flange Bolt Size (MM): M14 x 1.5
Flange Bolts Included: No
Flange Diameter (IN): 7.2
Flange Diameter (MM): 183
Flange Offset (IN): 1.84
Flange Offset (MM): 46.8
Flange Shape: Triangle
Hub Pilot Diameter (IN): 3.54
Hub Pilot Diameter (MM): 90
Spline Quantity: 33
Wheel Pilot Diameter (IN): 3.06
Wheel Pilot Diameter (MM): 77.7
Wheel Stud Quantity: 5
Wheel Stud Size (IN): 9/16-18
Wheel Studs Included: Yes
Generation: 3
Axle Splines Type: Insert CV Axle Directly
Wheel Bearing Grease: Yes (Pre-Greased)
Sealings Type: Inboard and Outboard

Package included:Front Wheel Hub and Bearing Assembly*2

Feature:
1. Intended to meet strict fatigue requirements to reduce premature failure.
2. After heat treatment, the surface is hardened to ensure high temperature resistance and durability.
3. Through rigorous testing, measurement, and inspection of materials and components, assembly and performance are ensured.
4. Includes an integrated seal made of self-lubricating rubber that has been optimized to maximize the removal of dirt and contaminants.
5. High carbon clean steel, running smoothly and quietly.

Note:

1.Before placing an order, please check your car model and do not only calculate the year and model. Please refer to the compatibility tab with annotations or send us a message to ensure a perfect match.
2.Before starting the installation, please take appropriate precautions and pay special attention to all precautions and warnings in the vehicle user manual.
3.If you are unsure how to install the parts or lack the necessary experience, please seek the help of qualified technicians.
