Techincal Parameters
- Operating voltage:DC12V+/-10%
- Operating curren:<100mA
- Ambient tempera:ture:0-60 C
- Relative humidity20%-90%
- Storeage:1000 users
- Card type: EM(ID) Card
- Card reading distance:0-10cm
Factory Default:
- Programming Password:123456
- Common access password:None.
- Relay Unloc:k output:5 seconds
- Open modeCard or access password（ access password include Private Access Password（PIN） and common Access Password.
- Security:OFF
- Backlight(For options):Auto
- WG26 port(For options）)Input
Light and sound indicates:
Light: red and green
Light Description | Indicates |
Red light flash every 1 sec(Slow flash) | Standby state |
Green light flash every 0.5sec(Fast flash) | Pending further action |
Red light is always ON. | Programming state |
Green light is always ON within Open time | Unlocking state |
Sound:Buzz
Sound Description | Indicates |
1 short buzz | Valid input |
3 short buzz | Invalid input |
1 long buzz | Programming success |
Continuous long buzz | Restoring factory programming passwords |
Installations:
JP1 terminal:
NO | Mark | Color | Function |
1 | +12V | Red | Power+ |
2 | GND | Black | Power- |
3 | PUSH | Blue | Low level output |
4 | OPEN | Yellow | Door Release |
5 | BELL | Grey | Bell |
6 | BELL | White | Bell |
JP2 terminal:
NO | Mark | Color | Function | Remark |
1 | NC | Brown | Relay NC output |
|
2 | COM | Blue | Relay COM output |
|
3 | NO | Purple | Relay NO output |
