Olympus Ulwd CDPLAN 40x/0.50 160/0-2 Microscope Objective microscope lens

Manufacturer: Olympus

Model: Ulwd CDPLAN 40x/0.50 160/0-2 microscope lens

Description:

The Olympus Ulwd CDPLAN 40x/0.50 160/0-2 is a high-quality microscope lens that was specially developed for applications where a particularly large work distance (ULWD = Ultra Long Working distance) is required. With a 40-fold magnification and a numerical aperture of 0.50, this objectively provides detailed, contrasting images and is ideal for observing samples in cultural vessels or petri dishes without touching or damaging the sample.

The tube length of 160 mm makes this lens compatible with many classic Olympus microscopes. The adjustable correction for deck glass thicknesses from 0 to 2 mm offers additional flexibility for different sample vessels and applications in cell culture, routine emicroscopy and research.

Olympus stands for optical precision, so this lens represents a reliable choice for high -quality microscopic examinations.

Specifications:

Type: microscope lens
Model: Ulwd CDPLAN 40X
Enlargement: 40 times
Numerical aperture (na): 0.50
Tubus length: 160 mm
Coverage thickness: 0–2 mm, adjustable
Special feature: Ultra Langer Work distance (ULWD) for comfortable working with cultural vessels

Technical details:

Work distance: especially large for a secure distance to the sample
Connection: RMS standard thread ( din )
Compatibility: Suitable for Olympus microscopes with 160 mm tube length
Areas of application: cell culture, life sciences, routine emicroscopy, research, observation of sensitive samples

Condition:

The Olympus Ulwd CDPLAN 40x/0.50 is in very good, well -kept condition. The lenses are clear and free of scratches.
