Ebike 40A 48V 60V 72V 1500W-2000W 3-Mode Sine Wave Controller With Display

Very important Notice:

This controller can only work without display or with our display, please never use it with your own display (because program is different)



Why 3-mode Controller?

Support Hall Sensor Mode (Sine Wave Mode)

Support Non-Hall Mode (If your motor hall sensor burned or not match, controller will still work in square wave mode)

Self-learning Function: Even wrong 3-phase combination between motor and

controller, doesn’t matter, above self-learning process can correct it!



Parts Including:

1. 18 MOSFET 40A 48V 52V 60V 72V Universal Voltage 1500W-2000W Intelligent 3-mode Sine Wave Controller

2. UKC1 Colorful Display or SW900 Display (Optional)

Technical Data of the Controller:

General Specification:

1. Rated Power: 48V 1000W/ 52V 1100W/ 60V 1200W/ 72V 1500W

2. Peak Power: 48V 1920/ 52V 2080W/ 60V 2400/ 72V 2880W

3. Brake: Low Voltage Brake

4. Alarm: Low Voltage Alarm

5. Rotor Position Detecting Method: Hall sensor

6. Size: 175x105x65mm

7. Net Weight: 900g

8. Waterproof Grade: IP65

9.Protocol: OMD Nr.2

Advantage:

1. Sine Wave Controller which support 3-mode (hall sensor mode, non-hall mode, self-learning) and smart match with each motor through self-learning, works with high efficiency, less noise, and lower energy consumption, which makes your electric vehicles or electric motorcycles more comfortable and easier to control, give you best pedal experience

2. Universal Input Voltage Range: 48V/52V/60V/72V

3. Work with or without display

4. Parameter setting via display

5. All protection make it long life and safe: over/under voltage, over current, over load, over heating, anti-runaway, locked-motor protection

6. Multi functions: Work with hall sensor mode or non-hall mode, smart match with different motor, 3/5/9-speed level for throttle and PAS, Current limit, Speed limit, Reverse, Push Assistant, Anti-thief, Regenerative Braking (Can set different level: Off, Standard, Weak, Strong), Speed detecting (Magnet quantity simulated or internal speed sensor) and etc.

7. Best heat sinking with Aluminium Case

8. Black anodized Aluminium Controller Case against scratch
