Fuling 5.5KW 220/380V Variable Frequency VFD Drive Inverter Speed Control 1000HZ
DZB312 series special inverter for carving machine is designed for carving machining industry, it adopts sine wave pulse
width vector control technology with specialized macro code function built-in, it's easy for installation and debugging,
reasonable wiring technology makes it stable and reliable.
Product features:
* It can realize 8 segment speed running for convenient macro card control
* Adopt 32-bit microprocessor and sine PWM control
* Unique core algorithm and low interference
* Adopt independent air duct for many dust occasions
* Automatic torque promotion and automatic slip compensation function
*Output frequency range 0~600.0Hz,customized up to 2000Hz
* Built-in standard 485 communication function
*Humanized design: Carving machine specialized macro code factory set parameters, easy for debugging
Applications
Various engraving machine, high speed motorized spindle;
Technical parameters；
◆ input voltage：3phase AC380V±15%
◆ Output power range：3phase AC380V±15%
◆ output frequency：0~600Hz，custom-made above 600Hz
◆ Input frequency 47~63Hz，power factor≥95%
◆ Control mode：Non-PG vector control, V/F control
◆ Source of operation instruction：given by panel, terminal and RS485 communication
◆ Source of given frequency：given by panel figure, analog quantity, RS485 serial communications, multi-speed simple PLC and PID etc.
◆ Overload capacity：130% rated current 60s、150% rated current 3s
◆ Carrier frequency：1.0kHz~15.0kHz，and can be automatically adjusted according to temperature and load characteristic.
◆ Frequency resolution：the given digital value is 0.01Hz，and the analog quantity is given as the highest frequency plus 0.1%
◆ Torque elevation：Manual torque can elevate 0~30%
◆ Inching operation：frequency range：0.0Hz~ Maximum output frequency Inching acceleration and deceleration time：0～3600.0s
◆ Simple PLC and multistage speed operation：it can realize up to 8 segments running
◆ Automatic voltage regulation： When grid voltage fluctuation occurred, it can automatically maintain constant output voltage;
Package include:
1 x Fuling Brand 5.5KW Inverter VFD 220V or 380V
Note:5.5KW 220V does not support braking resistor,5.5KW 380V can support a braking resistor.
