Detail
Main features
-DMR digital and analog compatible, mode rotation is excessively smooth
-UV double-segment, double-waiting(U-U, V-V, U-V, V-U)
-Wide band radio, support VHF136-174/UHF400-470
-1.77” TFT color screen, friendly man-machine interface
-Full numeric keyboard,manual writing frequency
-Digital noise reduction technology for clear calls even in noisy environments
-Dual-slot communication supports one channel and two groups of calls, saving spectrum resources
-Short message function, can send short message to the other party
-when it is not convenient to make a voice call One-button alarm,work alone
-Voice encryption to protect the privacy of business users' calls
-The private call, group call, all call, alarm call
-The call alerts, remote monitoring, remote death with activation
-Call real-time recording function(contact the dealer for large-ca pacity recording)
-The side keys function custom, without changing user habits
Specification
|
General |
|
|
Frequency Range |
VHF:136-174MHz, UHF:400-470MHz |
|
Memory Channel |
1024 |
|
Operating Voltage |
DC 7.4V |
|
Frequency stability |
±1.0ppm |
|
Demission |
136*62*36mm |
|
Battery Capacity |
2200mAh/16.28wh |
|
Weight |
Approach.274g |
|
Transmitter |
|
|
Output power |
High:5W Low:1W |
|
Adjacent channel power |
≤65dB ≤60dB |
|
Output consumption |
Analog≤1.6A |
|
Audio response |
+1~3dB |
|
Standby current consumption |
≤0.18A |
|
Digital Protocol |
ETSI-TS102 361-1,-2,-3 |
|
Modulation distortion |
≤5% |
|
Vocoder type |
AMBE+2 TM |
|
FM/FM modulation: |
16K￠F3E,25KHz |
|
4FSK/4FSK digital modulation |
12.5KHz for data:7K60FXD |
|
Signal-to-noise(wide/narrow) |
≥45dB,25KHz ≥40dB,12.5KHz |
|
Antenna Port Spurious |
9KHz-1GHz ≤-36dBm |
|
Receiver |
|
|
Analog receive sensitivity |
-122dBm (12dB SINAD) |
|
Digital receive sensitivity |
-122dBm (BER≤5%) |
|
Audio power |
1W |
|
Audio distortion |
<10% |
|
Signal imitation |
≥70dB |
|
Audio response |
+1~3dB |
|
Receive current |
≤380mA |
|
Intermediation(wide/narrow) |
≥62dB/≥58dB |
|
Adjacent channel selectivity |
≥65dB/≥60dB |
|
PM noise |
≥45dB,25KHz / ≥40dB,12.5KHz |
Standard Package:
1× DM-1702 Radio
1× 2200mAh Li-ion Battery Pack
1× Desktop Charger
1x AC Adapter(100-240V)
1×High gain Antenna
1× Hand Strap
1× Belt Clip
1× Earpiece
1× English Manual
(Other accessories are ordered based on the combination of accessories)
 |
 |
 |
 |
 |
 |
 |
 |
- Payment accepted by Paypal ,If you do not have Paypal account,Please sign up at www.paypal.com
- Payment must be received within 7 business days of auction closing.
- We ship it out from China.
- We ship the package to your paypal address. please make sure you can receive by it.
- All items are shipped within 1-5 days after payment cleared.
1. In our store, you will enjoy 60 days return/refund guarantee (Excluding misuse of the item and damaged item).
2. If the item you received is faulty, damaged or incorrect, or any further problems, you can return it for replacement or refund, please contact our customer service on eBay within 30 days from item received.
3. For damaged items on arrival, please contact us immediately, sending us an email with a photo is preferred. We will offer solutions to such cases. Full refund or replacement will be guaranteed.
- Any question,feel free to contact us freely.
- All emails will be answered within 24 hours. If you do not receive our reply, please kindly resent your email.
