4K Ultra HD
4K HDR video brings you closer to reality than ever with the finest details captured. Enjoy the best visual experience with 24/7 flawless streaming.
Person/Vehicle Detection
The AI-based system can detect people or vehicle from other objects, thus you will only get notified about things that matter.
Accurate Alerts in Real Time
Pushes Instant App notifications and emails attached with a snapshot whenever a person is detected, allowing for proactive actions to avert possible dangers.
Weatherproof for Outdoor
A full metal casing with an IP66 waterproof rating makes your super HD cameras work efficiently both indoors and outdoors.
Save Hard Drive Space
H.265+ coding compresses video file sizes without quality degradation, saving lots of storage space for longer recording time.
On Guard 24/7
This 4K camera kit covers every corner of your house 24/7 with up to 16 cameras recording continuously.
Protect What Matters Most
The camera system allows you to set up specific detection areas to focus on what you really care about.
| 8CH 4K PoE NVR Specifications | ||||
| Video/Audio Input | Video Intput | 8-CH , Up to 8MP resolution | 1 Channel VGA Output | 1920×1080，1280×1024，1024×768 |
| Audio Intput | Cameras with Built-In Mic | 1 Channel HDMI Output | 3840×2160，1920×1080，1280×1024，1024×768 | |
| Video & Audio Decoding Parameters | Video Compression | H.265 | Dual-Stream | Support dual stream network transmission (PC side, macbook, APP side) |
| Video Decoding Resolution | 8MP/5MP/1080P | Audio Compression Standards | G.711a | |
| Video Frame | Up to 5Mbps | Synchronous Playback | 4 Channels | |
| Code Stream Type | Variable Bit Rate | Image Settings | Support for front-end camera brightness, saturation, mirroring, image flip, color and other settings | |
| Hard Disk | Type | 1 SATA Interface | Maximum Capacity | Up to 8TB |
| Recording | Recording Mode | Manual recording, timed recording, motion detection recording | Playback Mode | Instant replay, regular replay, event replay, alarm replay |
| Backup Mode | General backup, event backup | |||
| Network | Wired Interface | 1x RJ-45 10/100 Mbps Self-Adaptive Ethernet Port | Client Side | Support windows system, macbook |
| Network Protocols | IPv4、TCP/IP、P2P、RTSP、NTP、SMTP | Phone | Support Android, ios system | |
| Permission | Support different levels of operating equipment permissions (channel access, video playback, remote viewing of specific channels permissions) | |||
| Smart Alarm | Mail Alert | Support (support emailing screenshots, attachments for main stream images) | Motion Detection | Support, motion detection range customizable, sensitivity 1-8 adjustable, the default is 4 |
| Human Detection | Support,human detection range customizable | Sound and Light Alarm | Support,various of alarm mode mode available | |
| Alarm Push | Support domestic and foreign mobile detection APP alarm push | |||
| Interface | Network Interface | 1, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Port | USB Interface | 3×USB 2.0 |
| Audio Output | 3.5mm audio interface×1 | POE Network Port | 8, Support 802.3af/at | |
| General | Power Supply | DC48V/2A | Power Consumption(Without HDD) | ≤96W |
| Working Temperature | -10℃～＋55℃ | Working Humidity | 10％～90％RH | |
| Dimensions | 230mm× 230mm ×42mm | Weight (Without HDD) | ≤0.85Kg | |
| 4K PoE Camera Specifications | ||||
| Camera | Resolution | 4K（3840*2160） | Image Sensor | 1/2.8" Progressive Scan CMOS |
| Lens | 4 mm @ F2.0 horizontal 90° | Lens Mount | M12 | |
| Minimum Illumination | 0.012Lux(color mode);0Lux（IR light on） | Infrared Light / White Light | 4+2 | |
| Infrared light Wavelength | 850nm | Day and Night Conversion Mode | ICR infrared filter type | |
| Infrared Night Vision Range | 30m | Full Color Night Vision Range | 20m | |
| Video | Maximum Image Size | 3840*2160(8MP), support dual streams | Frame Rate | Main stream:(20fps) Sub stream:(20fps) |
| Video Compression Standard | H.265/H.265+ Main Profile | Video Compression Bitrate | Main stream:5120kbps Sub stream:512Kbps | |
| Code Stream Type | Variable streams | Dual-stream | Main stream:（3840×2160）Sub stream: D1(640×360); | |
| Image Settings | Brightness; Contrast; Sharpness; Saturation (set by NVR, APP adjustment) | |||
| Audio | Audio Input | Built-in microphone | Audio Output | Built-in speaker |
| Audio Compression Standard | G.711A | |||
| Camera Features | White Balance | Automatic | Gain Control | Automatic |
| Digital Noise Reduction | 3D DNR | Backlight Compensation | Support | |
| Wide Dynamic | Support digital, hardware | Strong Light Suppression | Support | |
| Network | Wired Interface | 1, RJ-45 10/100 Mbps Self-adaptive Ethernet port | Support Protocols | IPv4；TCP；UDP；RTSP；RTP；DHCP；NTP； |
| Software Support | ZOSI Smart（Android/IOS） AVSS（PC/MacBook） | APP Maximum Support User Access | 5 | |
| Browser | Not supported | |||
| General Features | Intelligent Detection | Motion detection, human detection | Voice Function | Support two-way voice (half duplex) |
| Night Vision Type | Black and white night vision, night vision full color, intelligent night vision | Video Type | Full-time video, alarm video | |
| Alarm type | Light alarm, sound alarm, sound and light alarm, multiple alarm modes | Adjustable Installation Angle | Horizontal:0-360° vertical: 0-75° | |
| General | Power Supply | POE IEEE 802.3af 48V DC12V | Operating Conditions | -10℃～+60℃,humidity 95% or less(no condensation) |
| Power Consumption | MAX 6W | Protection Level | IP66（waterproof and dustproof） | |
| Material | Main body: Metal, Enclosure: Plastic | Dimensions | Φ127.2mm Height:116.4mm | |
| Weight | Approx 440g | |||
