NR10QC Universal Chromatic Meter Color-difference Meter Color Color Analyzer

The main advantages:

A low price;

2, higher short-term repeatability: ΔE≤0.03;

3, light and cross the double positioning;

4, configure a rechargeable lithium-ion battery, without repeated buy batteries;

5, Φ4mm measurement caliber, portable structure for more measurement occasions;

6, dark blue mainstream appearance, color box packaging fast, easy to transport;

7, built-in whiteboard parameters, without the need for a black and white plate correction;

8, without even the computer boot that is used - make measuring easier.

NR10qc Technical Specifications:

Illumination by light system 8 / d

Measuring caliber Φ4mm

Positioning light positioning and cross positioning

Color space CIE L * a * b *

Color difference  E * ab

Standard observer 10 ° viewing angle

Observed illuminant D65

Lighting LED blue light excitation

Sensor photodiode array

Storage capacity 100 standard 10,000 samples

Measuring the interval of about 1.5 seconds

Short-term repeatability 0.03ΔE * ab measure 30 times the average of the white standard plate

Power Rechargeable lithium-ion battery 3.7V@3200mAh power adapter (DC 5V)

TFT color screen 2.8inch @ (16: 9)

Lamp life is greater than three years, 1.6 million measurements

Charging takes about 8 hours to 100% capacity

After the charge can be measured within eight hours to measure the number 3000

Operating temperature range of 0 ~ 40 , 0 ~ 85% relative humidity (non-condensing)

Storage temperature range -10 ~ 50 , 0 ~ 85% relative humidity (non-condensing)

The difference between the short-term stations within ΔE * ab 0.20

Weight 450g

Size of 205 × 67 × 80 mm.
