Features:

1. Pure copper coil: The motor is made of high- rotor and high-quality materials, with high conductivity, high wear resistance and long life. At the same time, it adopts pure copper group, featured with small resistance, low heat generation, low loss, stable and sufficient power.

2. High quality carbon brush: Under the premise that other materials meet the requirements, it has good commutation performance, long service life, good electrical and thermal conductivity and good lubrication performance. The wear resistance degree of the carbon brush directly determines service life of the motor.

3. High strength magnetic tile: Long life, strong power, greater . Fully enclosed structure to prevent dust from entering the motor interior, simple structure, convenient maintenance. Small size, effective weight reduction, space saving, use.

4. Full metal gear: The gearbox are all made of high-quality metal gears, which have good impact resistance and durability. thus extending the lifespan of the gearbox.

5. Wide Application: This motor is ideal for intelligent toy car, robot, printer, balance car, smart home appliance, camera rocker arm, and so on.



Specification:

Rated speed (RPM): 1000, 500, 200, 130, 100, 60, 50, 40, 30, 20, 15, 10 (Optional)

:

Outer diameter: 25mm/0.98in

Shaft length: 12mm/0.47in

Shaft diameter: 4mm/0.16in

Reduction Ratio		No Load		Rated			Stall		L Size
	Raed Voltage	Speed	Current	Speed	Current			Current
	V	±10%RPM	A	±10%RPM	A	KG.CM	KG.CM	A	MM
4.4	12	1360	0.07	1000	0.3	0.1	0.4	1.8	18
9.6	12	620	0.07	500	0.3	0.2	0.9	1.8	17.5
21.3	12	280	0.07	200	0.3	0.4	2	1.8	19
35.5	12	170	0.07	130	0.3	0.69	3.3	1.8	21
46.8	12	130	0.07	100	0.3	0.9	4.4	1.8	21
78	12	77	0.07	60	0.3	1.5	5.5	1.8	23
103	12	60	0.07	50	0.3	2	7.3	1.8	23
130	12	46	0.07	40	0.3	2.5	9.2	1.8	25
171	12	35	0.07	30	0.3	3.3	Forbid stall or instantanous load reversal		25
226	12	26	0.07	20	0.3	4.4			25
377	12	16	0.07	15	0.3	7.3			27
500	12	12	0.07	10	0.3	9.7			27



Package list:

1 x Encoder Gear Motor
